Hilti PSA - Operation

*2004955*
2004955 English 17
PSA 86 PUA 86 19V
Rated input voltage
100 V … 240 V 10 V … 32 V
AC frequency
50 Hz … 60 Hz DC
Rated power
50 W 90 W
Rated output voltage
19 V 19 V
IP protection class
•/• •/•
Operating temperature
0 ℃ … 40 ℃ 5 ℃ … 40 ℃
Storage temperature (dry)
−25 ℃ … 60 ℃ −20 ℃ … 85 ℃
Charging temperature
0 ℃ … 40 ℃ 5 ℃ … 40 ℃
Weight
0.5 kg 0.52 kg
5 Operation
5.1 Inserting the battery 2
1. If the following equipment exists, also take this action:
PSA 80
▶ Hold the battery end cap so that it is facing you and the large groove on the battery is on the left.
▶ Slide the battery into the battery compartment.
▶ Turn the end cap clockwise until it engages.
2. If the following equipment exists, also take this action:
PSA 81
▶ Push the battery in until it engages securely.
▶ Check that the battery is securely seated in the tool.
3. If the following equipment exists, also take this action:
PSA 82
▶ Insert the battery at an angle into the battery compartment.
▶ Push the battery into the battery compartment until it is heard to engage.
▶ Check that the battery is securely seated in the tool.
4. If the following equipment exists, also take this action:
PSA 83
▶ Insert the end of the battery in the battery compartment.
▶ Push the battery into the battery compartment until it is heard to engage.
▶ Push the small slider on the back toward the battery compartment.
▶ Check that the battery is securely seated in the tool.
5.2 Removing the battery 3
1. If the following equipment exists, also take this action:
PSA 80
▶ Turn the end cap counterclockwise.
▶ Remove the battery from the tool.
Remove the battery only when the tool is switched off. Data may otherwise be lost.
