Project
Battery Input Voltage
Standby current
Unit
V
mA
Minimum
28
Max
55
0.1
Safest way to charge your battery-
First, assemble the charger by inserting the plug (Plug 1) into the transformer.
Then insert the DC plug (Plug 2) into the battery charging socket.
Last, insert the power plug (Plug 3: 110/220 volt plug) to the power socket. This order helps extend the battery life and effectively reduces battery
damage caused by improper charging.
The charger works on 110/220 V 56/60 Hz standard home AC power outlets. Do not open the charger to select voltage input as the charger can
automatically detect and account for incoming voltage.
Plug 1
Plug 2
Plug 3
Step 4:
30
Figure 8
