Himunication HM100 - Page 21

HM100
20
3.Rated audio output at 10% Thd
Speaker
mW
≥700
4.Max.S/N ratio at 1mV
dB
≥40
5.Audio frequency resp.
dB
1KHz/0dB ref.
@300Hz
dB
+7.5~+11.5
@2KHz
dB
-9~-5
@3KHz
dB
-12.5~-8.5
6.Adjacent ch.Rejection
dB
≥70
7.Image rejection
dB
≥70
8.Intermod rejection
dB
≥68
9.Spurious response rejection
dB
≥70
10.Scan time. Per channel
ms
≤200
11.StandBy Current
mA
≤40
12.Max Audio Power
mA
≤400
GENERAL STANDARD
1. Optional Floating Case With Flashes
2. Waterproof: IPX8
3. Communication Range: About 5 nautical miles
4. Build in Battery
VHF Radio DIMENSION & WEIGHT
Dimension (L/W/H)
mm
95×53×32
Weight
g
190
