Page 6
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
HUB AND SPINDLE/TIRE AND RIM
DWG. NO. 3014
HUB SUB-ASSEMBLY
DWG. NO. 1698
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
850-001-157
850-001-164
850-001-154
950-011-006
Hub Assembly W/Bearing Cups
Seal Triple Lip C/R #16286
Inner Bearing Cone JL69349
Wheel Bolt 1/2 x 1
1
1
1
6
5
6
7
8
955-001-001
850-001-159
850-001-158
850-001-555
Grease Fitting
Inner Bearing Cup JL 69310
Outer Bearing Cup LM 67010
Wear Sleeve
1
1
1
1
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
805-001-096
850-001-153
802-000-007
951-005-002
Axle Weldment
Hub Sub-Assembly (See Below)
Outer Bearing Cone LM 67048
Washer
Slotted Nut 7/8-14 UNF
1
1
1
1
1
6
7
8
9
10
850-001-155
953-001-017
850-001-004
850-001-093
850-001-396
Hub Cap
Cotter Pin 5/32 x 1 1/2
Tire-6 Ply 9.5L x 15”
Rim-6 Bolt 8 LB. x 15”
Tire Valve
1
1
1
1
1
