Hiniker 6000 - Hydraulic Plumbing Single Lift Assist Wheel

Page 7
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
DIRECTION
OF FLOW
30
O
1
2
3
4
6
8
7
9
10
5
1
1
11
HYDRAULIC PLUMBING SINGLE LIFT ASSIST WHEEL
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
956-004-002
957-002-015
956-005.003
81004503
957-002-016
921-001-145
Reducer Bushing 1/2-14 MNPT To 3/8-18 FNPT
Hose Assembly 3/4 x 108 Inch Long
Elbow 90
o
1/2-14 MNPT To 9/16-18 Male 37
o
JIC
Cylinder 3 x 8, 3/4-16 O-Ring Ports (See Sec. 3 Pg. 8)
Hose Assembly 3/8 x 126 Inch Long
Plastic Cable Tie 21 Inches Long
3
1
1
1
1
3
7
8
9
10
11
921-001-144
956-003-020
956-007-002
956-008-022
956-005-001
Plastic Cable Tie 14 Inches Long
Straight Adapter 3/4-16 O-Ring To 1/2-14 MNPT
Tee 1/2-14 FNPT
Relief Valve 3/8-18 FNPT
Elbow 90
o
3/4-16 O-Ring To 9/16-18 Male 37
o
JIC
3
1
1
1
1
DWG. NO. 2861A
