Hiniker 6000 - Hydraulic Plumbing Dual Lift Assist

Page 8
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
NOTE: PIVOT ITEMS 9 (TEE) 30° TO THE RIGHT.
6
10
9
8
1
7
11
6
10
11
7
9
1
8
4
5
3
3
3
2
1
1
2
3
4
5
DIRECTION
OF FLOW
DIRECTION
OF FLOW
30°
30°
BULKHEAD BRACKET
HYDRAULIC PLUMBING DUAL LIFT ASSIST
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
956-004-002
957-002-014
956-007-003
957-001-017
957-001-058
81004503
Reducer Bushing 1/2-14 MNPT To 3/8-18 FNPT
Hose Assembly 3/8 x 48 Inches Long
Bulkhead Tee 9/16-18 Male 37
o
JICTo 9/16-18 Male 37
o
JIC On Run 9/16-18 Male 37
o
JIC Bulkhead On Bracket
Hose Assembly 3/8 x 72 Inches Long
Hose Assembly 3/8 x 82 Inches Long
Stroke Cylinder 3 Inch Diameter x 8 Inch With
3/4-16 O-Ring Port (See Sec. 3 Page 8)
4
2
2
2
2
2
7
8
9
10
11
956-005-003
956-003-020
956-007-002
956-008-022
956-005-001
Elbow 90
o
1/2-14 MNPT To 9/16-18 Male 37
o
JIC
Straight Adapter 1/2 MNPT To 3/4 Male ORB
Street Tee 1/2 FNPT
Relief Valve 3/8 FNPT
Elbow 90
o
3/4-16 Male ORB To 9/16-18 Male 37
o
JIC
2
2
2
2
2
DWG. NO. 2925
