HIOS BLOP-STC 3 - Page 9

●
Operating display LED
•
Lights green when the power is switched on.
•
Lights orange when operation of the electric screwdriver is enabled.
●
Number of screws display
•
Displays the set number of screws to be tightened initially and displays the remaining
number of screws to be tightened after counting starts.
•
Each time a screw is tightened, the remaining number of screws to be tightened is
reduced by one.
●
Reset switch (RESET)
•
This resets the counter functions, interrupts output of the valve signal and releases the
work piece held by an external device.
•
If operated during or after setting the set switch, the display returns to the number that
was set.
•
Performs the same function as the reset on the terminal block on the rear panel.
●
Function switch (F1)
•
Enters change function mode if pressed for more than 1 second after reset (Display "
").
•
Pressing the button for longer than 1 second while in Change Function Mode will cause
a buzzer to sound, shutting down the Change Function Mode.
●
Function switch (F2, F3) (x10, x1 Setting Switch)
•
Numbers increase in increments of 1 as the button is pressed.
A limit may be imposed depending on the setting being changed.
1) Count Setting Mode (Display "
")
•
Set the number of screws to be tightened from 1 to 99.
•
Set the position for 10 and 1 .
A setting of 00 cannot be entered (warning buzzer will sound).
2) CN-T (Count Timer) Setting Mode (Display "
")
•
Setting range from 0.01 second to 0.99 second.
•
 ThisSWsettingpreventscountingthesecondtighteningofascrewduetoconrmation
or additional tightening.
•
The buzzer will sound for a short time while countdown is possible.
 Usethebuzzerwhileconrmingthetightnessofscrewsthathavebeentightenedasa
guide to setting the count timer operating time.
(The screwdriver will only operate while the count timer is running, regardless of other
settings)
