6 Technical data
 General technical data
Weight EAGLE..-.........999S.. ca. 1,2 kg
EAGLE..-.........999T..
EAGLE..-.........999E..
ca. 1,5 kg
Power supply
Working voltage
with the
characteristic
value C
 Relevant for North America: Class 2
Nominal voltage DC 24 V ... 48 V
Class 2
Voltage range DC incl.
maximum tolerances
18 V ... 60 V
Class 2
Voltage range DC in
Hazardous Locations (Class I,
Division 2) incl. maximum
tolerances
22 V ... 52 V
Connection type 2-pin terminal block
Power failure bypass > 10 ms at 20.4 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
6.3 A
slow blow
Peak inrush current < 4 A
Power supply
Working voltage
with the
characteristic
value K
Nominal voltage AC 110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC 88 V ... 265 V, 47 Hz ... 63 Hz
Voltage range AC in
Hazardous Locations (Class I,
Division 2) incl. maximum
tolerances
99 V ... 253 V
Nominal voltage DC 60 V ... 250 V
Voltage range DC incl.
maximum tolerances
48 V ... 320 V
Voltage range DC in
Hazardous Locations (Class I,
Division 2) incl. maximum
tolerances
54 V ... 275 V
Connection type 3-pin terminal block
Power failure bypass > 10 ms at 98 V AC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
2.5 A
slow blow
Peak inrush current < 3.5 A
