Damped oscillation - AC/DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — — — 1 kV
Damped oscillation - data line
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12 line/line — — — ± 1 kV
Pulse magnetic fields
EN 61000-4-9 — — 300 A/m —
Stability Standard
applications
Navy applications Railway
applications
Substation
applications
IEC 60068-2-6, test Fc Vibration 5 Hz ... 8.4 Hz with
0.14 in. (3.5 mm)
amplitude
2 Hz ... 13.2 Hz
with
0.04 in. (1 mm)
amplitude
— 2 Hz ... 9 Hz with
0.12 in. (3 mm)
amplitude
8,4 Hz ... 150 Hz
with 0.04 oz (1 g)
13.2 Hz ... 100 Hz
with 0.7 g
9 Hz ... 200 Hz
with 0.04 oz (1 g)
200 Hz ... 500 Hz
with 0.05 oz (1.5 g)
IEC 60068-2-27, Test Ea Shock 0.53 oz (15 g) at
11 ms
— — 0.35 oz (10 g) at
11 ms
EMC interference
immunity
Standard
applications
Navy applications Railway
applications
Substation
applications
