Installation EAGLE20/30
Release
06
04/2014
45
IEEE 1613 80 MHz ... 1000 MHz — — — 35 V/m
Fast transients (burst)
EN 61000-4-4
IEEE C37.90.1
AC/DC supply connection ± 2 kV ± 2 kV ± 2 kV ± 4 kV
EN 61000-4-4
IEEE C37.90.1
Data line ± 4 kV ± 1 kV ± 2 kV ± 4 kV
Voltage surges - DC supply connection
EN 61000-4-5
IEEE 1613
line/ground ± 2kV ± 1kV ± 2kV ± 5kV
EN 61000-4-5 line/line ± 1 kV ± 0.5 kV ± 1 kV ± 1 kV
Voltage surges - AC supply connection
EN 61000-4-5
IEEE 1613
line/ground ± 2kV ± 1kV ± 2kV ± 5kV
EN 61000-4-5 line/line ± 1 kV ± 0.5 kV ± 1 kV ± 2 kV
Voltage surges - data line
EN 61000-4-5 line/ground ± 1 kV — ± 2 kV ± 4 kV
Conducted disturbances
EN 61000-4-6 150 kHz ... 80 MHz 10 V 10 V 10 V 10 V
EMC interference
immunity
Standard
applications
Navy applications Railway
applications
Substation
applications
