Hisense 43A7100F User Manual

16
Specifications
Item
55" 65"
Dimension
(W × H × D)
Without Stand
48.4 × 28.0 × 3.3 inches
(1230 × 712 × 85 mm)
57.0 × 32.8 × 3.2 inches
(1448 × 834 × 81 mm)
With Stand
48.4 × 30.5 × 11.5 inches
(1230 × 774 × 291 mm)
57.0 × 35.2 × 11.4 inches
(1448 × 894 × 290 mm)
Weight
Without Stand
27.1 lbs (12.3 kg) 36.8 lbs (16.7 kg)
With Stand
27.8 lbs (12.6 kg) 37.5 lbs (17.0 kg)
Active Screen Size (Diagonal)
139 cm 164 cm
Screen resolution
3840 × 2160 3840 × 2160
Audio power
8W + 8W 10W + 10W
Operating mode power density
0.016 Watts/cm² 0.014 Watts/cm²
Power consumption when turned off
< 0.5 W < 0.5 W
Power consumption in standby mode
0.5 W 0.5 W
Power consumption
Please refer to the rating label.
Power supply
Please refer to the rating label.
Receiving
systems
Analog
PAL-D/K, B/G, I, SECAM-D/K, B/G
Digital
DVB-T/T2, DVB-C, DVB-S/S2
Wireless
LAN Module
specifications
Model
WTA1M2500
Frequency
Range
2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz 17dBm
Bluetooth
Module
specifications
Model
WTA1M2500
Frequency
Range
2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz, Class1, 6dBm
Environmental conditions
Temperature: 5°C - 45°C
Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa
HDMI Input
RGB / 60 Hz (640×480, 800×600, 1024×768)
YUV / 60 Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
YUV / 50Hz (576 I, 576 P, 720 P, 1080 I, 1080 P)
3840×2160 / 24Hz, 3840×2160 / 25Hz
3840×2160 / 30Hz, 3840×2160 / 50Hz,
3840×2160 / 60Hz
