Hisense 50E77HQ User Manual

- 13 -
12
GND
12
GND
13
12VS/ VCC2
13
12VS/ VCC3
14
12VS/ VCC1
14
12VS/ VCC2
15
12VS/ VCC2
15
12VS/ VCC3
16
GND
16
GND
XP14：51pin VBO to Tcon board
Tcon
Main board
Pin
定义
说明
Pin
Config
1
V
DD
Power Supply Input Voltage
51
12V-Panel
2
V
DD
Power Supply Input Voltage
50
12V-Panel
3
V
DD
Power Supply Input Voltage
49
12V-Panel
4
V
DD
Power Supply Input Voltage
48
12V-Panel
5
V
DD
Power Supply Input Voltage
47
12V-Panel
6
V
DD
Power Supply Input Voltage
46
12V-Panel
7
V
DD
Power Supply Input Voltage
45
12V-Panel
8
V
DD
Power Supply Input Voltage
44
12V-Panel
9
NC
No Connection
43
12V-Panel,L65 NC
10
GND
Ground
42
GND,R223--0Ω
11
GND
Ground
41
GND,R217--0Ω
12
GND
Ground
40
GND,R222--0Ω
13
GND
Ground
39
GND,R216--0Ω
14
GND
Ground
38
GND,R221--0Ω
15
NC
No Connection
37
DATA FORMAT0 R479,R495 NC
16
NC
No Connection
36
DATA FORMAT1R480,R502 NC
17
NC
No Connection
35
Mplusmodel1R207,R213,R485,R
526 NC
18
SDA
I
2
C Data signal
34
Panel_I2C_SDA
V16OK,R214,R816--0Ω
R326,R332--10K，C271 NC
19
SCL
I
2
C Data signal
33
Panel_I2C_SCL
V15,R818,R224OK
20
NC
NC
32
I2C_WP
R219,R318,R215,R220,V30,R22
0,R208,R338,R540,R799,R797N
C
21
NC
No Connection
31
Bit_sel
R825,R483,R524,R564,R798 NC
22
SEL_S
ECTIO
Low or NC: 2 section(default)
High: 4 section
30
Data format
R218NC,R478NC,R486
