The side at which the door opens can
be changed, from the left side (as
supplied) to the right side, if the
installation site requires.
Warning! When reversing the door, the
appliance must not be connected to the
mains. Ensure that the plug is removed
from the mains socket.
Tools you will need:
8mm socket wrench
Cross-shaped screwdriver
8mm wrench
Thin-blade screwdriver
Note: Before you start lay the
refrigerator on its back in order to
gain access to the base, you should
rest it on soft foam packaging or
similar material to avoid damaging
the backboard of the refrigerator. To
reverse the door, the following steps
are generally recommended.
1. Stand the refrigerator upright.
2. Remove part and part from
the refrigerator body, and then take
down part on the door in the same
way. Remove the part screws ,then
take off part as the picture below.
Note: Please hold the freezer door by hand
during step 2 to prevent door dropping.
9
3. Take off the door and place it
on smooth surface with panel upwards.
Screw out the hinge axis (include
washer) as show figure and
and then turn the upper hinge
fixed board over as show figure
. Finally fix parton partas
show figure and ,then place it at
side for use.
Upper hinge cover
Top cover block
Cover plate
Special flange self-
tapping screw
Upper hinge part
