10
5. Remove the hinge hole cover from the
left holes as illustrated and transfer them
to the uncover hole at the right side.
6. Remove the screw nail of the door
stopper, and transfer them to the left sid
of the door, then tight the screw nail.
7. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts, and
remove the front feet fixed board and the
lower hinge part by unscrewing the
special flange screws.
8. Unscrew the bottom hinge axis and
remove it to the hole which is side-by-side
and screw it.
screw hole covers
screw hole covers
front feet fixed board
lower hin
To Next Page
