7677 board external terminals description:
Terminal
Terminal description
remark
XS3
Digital Audio out
XS2
Earphone out/Audio out
composite
XS6
COMPONENT Video input
XS5
AV/COMPONENT Audio input
composite
XS7
HDMI1/MHL input
4K@60Hz
XS8
HDMI2/ARC input
4K@60Hz
XS10
HDMI3 input
4K@30Hz
XS12
LAN
XS14
USB2（2.0）
XS15
USB3（3.0）
U7
RF input
CDT-940IM324-SL20\ROH
ISDB-T
XP6
IR/Key/WIFI/BT
XP3
Speaker
XP4
VBI
XP8
Local dimming
XP1
Main power input
