6888 board external terminals description:
Terminal
Terminal description
remark
XS3
Digital Audio out
XS2
Earphone out/Audio out
composite
XS6
COMPONENT Video input
XS5
AV/COMPONENT Audio input
composite
XS7
HDMI1/MHL input
4K@60Hz
XS8
HDMI2/ARC input
4K@60Hz
XS9
HDMI3 input
4K@30Hz
XS12
LAN
XS13
USB1（2.0）
XS14
USB2（2.0）
XS15
USB3（3.0）
U3
RF input（AJ063-F01T1NY-A\Reflow\ROH ）
