4.1.2 TCON software and backlight drive software upgrading directly with USB
1、Take Chassis MTK5658 HE70M9710UWTSG for example. TCON upgrading file named
“frc_HA50M5010UWT.bin” .
2、Take Chassis MTK5658 HA50M5010UWT for example. backlight upgrading file named “blu.bin”
3、If the TV need upgrade the main software、TCON software and backlight software respectively, then the three
upgrade softwares must be saved in three different USB disks that no other same names in .
4、The TCON and back light update process same to main software upgrading directly with USB(as following)
Insert the USB Disk to TV USB port, AC power off then AC power on the TV. at the
same time press standby button “ ” on the remote control for about 5-10s,until pop up
the update process bar.
The TV will identify the software and upgrade automatically.
After update success, TV can automatically start.
5、Enter the Factory OSD Menu and ensure the FRC version and BLU version.
