View the control panel and connection panel
The appearance is different from each model,please refer to the actual units.
AC INPUT
TV Front
TV Rear
AUDIO OUT
DIGITAL AUDIO OUT
PC
PC/DVI AUDIO IN
HDMI1
SERVICE HEADPHONE ANT/CABLE IN
INPUT
