2. Take out the ice storage box(2)
(if equipped).
3. Remove the 2 screws(3) fixed on the
upper drawer with Phillips(+)
screwdriver.
4. Take out the upper drawer by lifting it
up from the rail system.
1
2
3
1
5. Take out the lower drawer(5) by lifting it
up.
6. Remove the 2 screws(6) holding the
support with Phillips(+) screwdriver.
5
6
6
10
