Installing your new appliance
4. Use a 5 mm Allen wrench to
remove the four hex head hinge
bolts (two per hinge) on the lower left
and rights sides of your refrigerator,
then remove the hinges.
6. Lift the lower freezer drawer up and
out.
Hinge
Hinge bolts
Allen wrench
5. Pull the freezer compartment door
and the upper freezer drawer fully
open.
Lower freezer drawer
7
. Remove the two screws that secure
that support frame.
Lower freezer drawer
12
