11
4. Use both hands to open the door
more than 90°. Lift it up and take it
off.
＞90°
5. Remove the 4 hex head bolts
hinges with an Allen wrench
(5/32",4mm). Remove the lower left
and right door hinges.
Disassembling the freezer door
1. Pull out the freezer door and the
upper freezer drawer to the final
position.
2. Take out the ice storage box (if
equipped).
Upper freezer
drawer
Ice storage box
Hinge
Hinge bolts
Allen wrench
Installing your new appliance
