CHASSIS
- 159-
5315
SDO Send Error
Internal CANbus fault
5316
SDO unknown event
Internal CANbus fault
5317
SDO Bad SRC
Internal CANbus fault
5318
SDO bad error number
Internal CANbus fault
5319
Motor slave in wrong state
Motor slave in wrong state
531A
Ren Protocol
CAN device on Renault Twizy not responding
5341
Invalid DSP Protocol
DSP reports invalid protocol version on dual
processor platform
5342
OSC Watchdog Fault
Internal hardware fault
5343
Fault List Overflow
Attempting to set too many faults.
5344
DSP SPI Comms Fault
Communication error between host and DSP
processors (or gate drive and MCP)
5345
Scheduler stack overflow fault
Less than 10% of the stack is free on one of the
RTOS tasks.
5346
Internal supply out of range fault
An internal logic supply rail has gone out of
range
5381
CANopen anon EMCY level 4
EMCY message received from non-Sevcon node
and anonymous EMCY level (0x2830,0) is set to
4.
5441
Incompatible hardware version
Detected controller hardware version
incompatible with software
5442
Calibration Fault
Calibration settings in controller are out of range
54C1
PFOvervoltage
Voltage on B+ terminal exceeds rated maximum
for controller
54C2
Powerframe Fault
Motor current exceeded controller rated
maximum
54C3
MOSFET s/c M1>B+
MOSFET / IGBT s/c detection on M1 top devices
54C4
MOSFET s/c M1>B-
MOSFET / IGBT s/c detection on M1 bottom
devices
54C5
MOSFET s/c M2>B+
MOSFET / IGBT s/c detection on M2 top devices
54C6
MOSFET s/c M2>B-
MOSFET / IGBT s/c detection on M2 bottom
devices
54C7
MOSFET s/c M3>B+
MOSFET / IGBT s/c detection on M3 top devices
54C8
MOSFET s/c M3>B-
MOSFET / IGBT s/c detection on M3 bottom
devices
54C9
MOSFET s/c checks incomplete
Unable to complete MOSFET / IGBT s/c tests at
power up
54CA
Pump Mosfet S/C
MOSFET / IGBT s/c detection Pump Mosfet
Devices
54CA
IGBT M1 Low Driver Fail
IGBT driver failure
54CB
IGBT M1 High Driver Fail
IGBT driver failure
