Rearview
QUICKGUIDE
IMPORTANT-IfplacingTVintocabinetoralcove,ensurethereisatleasta100mm(10cm)gaptothesides,
rearandtopoftheTV.Thisistoallowforadequateventilationduringoperation.Pleasereadthe
mainUsersGuideformoresafetyinformationbeforeinstallation.
insertthebatteriesintoyourhandset
eitherconnecttheaerialstraighttoyourTV...
...orconnecttheaerialthroughaVCR...
•ItisrecommendedthatascartleadshouldbefittedbetweenyourTVandVCRtoenhanceyourpictureandsound
quality.ScartleadsareessentialifyouhaveastereoTVandVCRandwishtoobtainstereosoundfromyour
equipment.TheseleadscanbepurchasedfromyourHitachidealeroranygoodHighStreetelectricalretailer.
26LD6600
GB
MENUP/CHVOLUME
STANDBY
AV
Aerial(RF)Socket
wall
socket
Aerial(RF)
Lead
ANT.IN
VCR
AV-1
AV-2
Aerial(RF)Socket
wall
socket
Aerial(RF)
Lead
OptionalScartLead
TVtoVCR
Aerial(RF)SocketVCR
(RF)connector
leadVCRtoTV
TFT-LCDTV
**Incaseofanyabnormalbehaviourwiththedevicesconnectedtoscart1,pleaseusescart2
Scart1
Scart1
Scart2
Scart2
