Hitachi 42PD3000 User Manual

9
plasma screen, AVC unit and equipment connection
set-up
Connect aerial connection lead to the Digibox ‘in’
socket marked
.
4
Connect Digibox ‘out’ to VCR ‘in’ socket marked
.
Connect VCR ‘out’ to TV ‘in’ socket marked .
5
6
VHS video equipment
should be connected to the
AV1 scart socket located at
the rear of your TV. A
dedicated programme
number may be assigned to AV1,
allowing you easier access to
external equipment viewing. How
to assign an AV signal to
dedicated programme numbers is
explained in signal source entry
section.
CENTER
AUDIO IN
VIDEO OUT
AUDIO OUT
S-VHS
L
Y
C B
R
L
R
P R
C B
P R
FMS5011
Y
C B
L
R
P R
C B
P R
2
EUROPE
1
LINK LEAD
3
U.K. ONLY
AUDIO VISUAL CONTROL
(AVC) UNIT
6
U.K. ONLY
PLASMA SCREEN
Placing the AVC vertically
Vertical Stand
Attachment screw for stand
Side of the AVC
*Please make sure to use the
attachment screws for the vertical
stand when placed vertically.
*Arrows in the vertical stand should
point out towards the front side of the
AVC.
X832136-02-02(En) 9/13/02 10:38 AM Page 9
