117
QH01 G HV DRIVE IN QH01 D HV OUT I902 Pin 1 DEF SWITCHED OUT
I901 Pin 7 STBY SWITCHED OUT
49
50
51
52
IMPORTANT NOTE: FOR HOT AREA USE AC CORD WITH FLOATING GROUND
Click on number to go to schematic
DP65
