PRINTED CIRCUIT BOARDS
DP65 DCU PWB (Solder side)
DP65
148
SEMICONDUCTOR LOCATION
(Solder side)
A
B
C
D
1 2 3 4 5
IS03 B-5
IS04 B-5
IS06 B-4
IT01 A-1
QS03 D-3
QS04 D-2
TRANSISTOR
IC
