Hitachi 57F59A - Page 157

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
156
DP65
SYMBOL PART # DESCRIPTION SYMBOL PART # DESCRIPTION
C340 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK C539 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C341 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C540 AA01123R CCC105K10-B-16CT
C342 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C541 AA01123R CCC105K10-B-16CT
C343 AA01113R CCC225K06-B-16CT C542 0893188R CERAMIC CAPACITOR(47000PF 16V)
C344 AA01113R CCC225K06-B-16CT C543 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C345 AA01123R CCC105K10-B-16CT C544 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C346 AA01123R CCC105K10-B-16CT C545 AA01123R CCC105K10-B-16CT
C347 AA01123R CCC105K10-B-16CT C546 AA01123R CCC105K10-B-16CT
C348 0800352R CAP.-ELECTRO.470UF 10V C547 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C350 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK C548 AA01123R CCC105K10-B-16CT
C352 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C549 AA01123R CCC105K10-B-16CT
C353 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C550 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C354 0800352R CAP.-ELECTRO.470UF 10V C551 AA01123R CCC105K10-B-16CT
C355 AA01802R CCC103K50-B-16CT MCH18 C552 AA01123R CCC105K10-B-16CT
C356 0800352R CAP.-ELECTRO.470UF 10V C553 AA01123R CCC105K10-B-16CT
C357 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C554 AA01123R CCC105K10-B-16CT
C358 AA00969R CAP.CHIP2125-B-22UF6.3V C555 AA01802R CCC103K50-B-16CT MCH18
C361 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C556 0800326R CAP.-ELECTRO. 100UF-M 16V
C364 AA01115R CAP.CHIP1608-B-4.7UF6.3V C557 AA01802R CCC103K50-B-16CT MCH18
C365 AA01113R CCC225K06-B-16CT C558 0800326R CAP.-ELECTRO. 100UF-M 16V
C366 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C559 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C367 AA01123R CCC105K10-B-16CT C560 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C368 AA01123R CCC105K10-B-16CT C561 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C369 AA01802R CCC103K50-B-16CT MCH18 C562 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C370 AA01802R CCC103K50-B-16CT MCH18 C563 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C372 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C564 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C373 AA01802R CCC103K50-B-16CT MCH18 C566 AA01123R CCC105K10-B-16CT
C374 AA01802R CCC103K50-B-16CT MCH18 C567 AA01123R CCC105K10-B-16CT
C375 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C568 AA01123R CCC105K10-B-16CT
C376 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C569 AA01123R CCC105K10-B-16CT
C377 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C570 AA01802R CCC103K50-B-16CT MCH18
C378 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C571 0800326R CAP.-ELECTRO. 100UF-M 16V
C379 0800326R CAP.-ELECTRO. 100UF-M 16V C572 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C380 AA01115R CAP.CHIP1608-B-4.7UF6.3V C573 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C381 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C574 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C382 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C575 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C383 AA01802R CCC103K50-B-16CT MCH18 C576 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C384 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C580 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C390 0893222R CAP 1608CHIP10000PFKB 50V TAPE C582 AA01802R CCC103K50-B-16CT MCH18
C501 AA01123R CCC105K10-B-16CT C583 AA01802R CCC103K50-B-16CT MCH18
C502 AA01123R CCC105K10-B-16CT C584 0800326R CAP.-ELECTRO. 100UF-M 16V
C503 AA01123R CCC105K10-B-16CT C585 0800326R CAP.-ELECTRO. 100UF-M 16V
C504 AA01123R CCC105K10-B-16CT CA01 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C505 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA02 AA00982R CERAMIC CAPACITOR(0.33UF 25V-B
C506 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA03 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C509 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA04 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C510 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA05 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C511 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA06 AA00991R CERAMIC CAPACITOR(0.1UF 50V-B)
C512 AA01123R CCC105K10-B-16CT CA07 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C513 AA01123R CCC105K10-B-16CT CA08 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C514 AA01802R CCC103K50-B-16CT MCH18 CA09 0893213R CAP1608CHIP 2200PFKB 50V TAPE
C515 AA01802R CCC103K50-B-16CT MCH18 CA10 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C516 AA01115R CAP.CHIP1608-B-4.7UF6.3V CA11 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C517 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) CA12 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C518 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) CA13 0893213R CAP1608CHIP 2200PFKB 50V TAPE
C519 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) CA14 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C520 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CA15 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
C521 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA24 AA01802R CCC103K50-B-16CT MCH18
C522 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA25 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C523 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA26 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C524 AA01123R CCC105K10-B-16CT CA27 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C525 AA01123R CCC105K10-B-16CT CA28 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C526 AA01123R CCC105K10-B-16CT CA29 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C527 AA01123R CCC105K10-B-16CT CA30 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C528 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CA31 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
C529 0800326R CAP.-ELECTRO. 100UF-M 16V CA32 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
C530 0893188R CERAMIC CAPACITOR(47000PF 16V) CA33 0800318R CAP.-ELECTRO. 47UF-M 25V
C531 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA34 0800318R CAP.-ELECTRO. 47UF-M 25V
C532 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA35 0800328R CAP. ELECTRO. 100UF-M 35V
C533 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CA36 0880194R CAP.-POLYESTER 0.1UF-J 50V
C534 AA01802R CCC103K50-B-16CT MCH18 CA37 0880194R CAP.-POLYESTER 0.1UF-J 50V
C535 0800352R CAP.-ELECTRO.470UF 10V CA38 0880194R CAP.-POLYESTER 0.1UF-J 50V
C536 0800352R CAP.-ELECTRO.470UF 10V CA39 AL01153S CAP.ELECTR. 1000UF-M 35V
C537 0893188R CERAMIC CAPACITOR(47000PF 16V) CA41 0284824F CAP.-ELECTRO. 2200UF 35V
C538 AA01121R CERAMIC CAPACITOR(0.47UF 10V) CA42 0284824F CAP.-ELECTRO. 2200UF 35V
