PRODUCT SERVICE NOTE:Components marked with a have special characteristics important to safety.Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
SYMBOL PART # DESCRIPTION SYMBOL PART # DESCRIPTION
CA43 0880181R CAP.METAL-POLY.FLM 0.01UF 50V CX18 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA44 0880181R CAP.METAL-POLY.FLM 0.01UF 50V CX19 AA01802R CCC103K50-B-16CT MCH18
CA47 0800321R CAP.-ELECTRO. 47UF-M 50V CX20 0284634R CAP.-ELECTRO 4.7UF-SME(BP) 50V
CA48 0800329R CAP.-ELECTRO. 100UF-M(SMG) 50V CX21 AA01802R CCC103K50-B-16CT MCH18
CA49 0800288R CAP.-ELECTRO. 4.7UF-M(SMG) 50V CX22 0800352R CAP.-ELECTRO.470UF 10V
CA50 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CX23 AA01802R CCC103K50-B-16CT MCH18
CA52 0800326R CAP.-ELECTRO. 100UF-M 16V CX24 AA01113R CCC225K06-B-16CT
CA53 0800352R CAP.-ELECTRO.470UF 10V CX25 AA01113R CCC225K06-B-16CT
CA54 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CX26 AA01113R CCC225K06-B-16CT
CC01 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CX27 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC02 0800359R CAP.-ELECTRO. 1000UF-M 10V CX28 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC03 0800344R CAP.-ELECTRO. 330UF-M(SMG) 16V CX29 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC04 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CX30 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC05 0893213R CAP1608CHIP 2200PFKB 50V TAPE CX31 0800359R CAP.-ELECTRO. 1000UF-M 10V
CC06 0800288R CAP.-ELECTRO. 4.7UF-M(SMG) 50V CX32 AA01802R CCC103K50-B-16CT MCH18
CC08 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V CX38 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC09 0893205R CAP 1608CHIP 560PFKB 50V TAPE CX39 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC10 0893186R CERAMIC CAPACITOR(33000PF 16V) CX40 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC11 0800326R CAP.-ELECTRO. 100UF-M 16V CX41 AA01802R CCC103K50-B-16CT MCH18
CC12 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CX42 0800326R CAP.-ELECTRO. 100UF-M 16V
CC13 0800353R CAP.-ELECTRO.470UF-M 16V CX43 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC14 0893211R CAP 1608CHIP 1500PFKB 50V TAPE CX44 0800326R CAP.-ELECTRO. 100UF-M 16V
CC15 0893128R CAP 1608CHIP 150PFJCH 50V TAPE CX45 AA01802R CCC103K50-B-16CT MCH18
CC17 0800326R CAP.-ELECTRO. 100UF-M 16V CX48 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC19 0800326R CAP.-ELECTRO. 100UF-M 16V CX49 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC20 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CX52 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC21 0800328R CAP. ELECTRO. 100UF-M 35V CX53 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC22 AA01802R CCC103K50-B-16CT MCH18 CX56 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC23 AA01802R CCC103K50-B-16CT MCH18 CX57 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC24 AA01802R CCC103K50-B-16CT MCH18 CX58 0800352R CAP.-ELECTRO.470UF 10V
CC25 AA01123R CCC105K10-B-16CT CX59 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC26 AA01123R CCC105K10-B-16CT CX60 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC27 0800334R CAP.-ELECTRO. 220UF 10V CX61 0800326R CAP.-ELECTRO. 100UF-M 16V
CC28 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CX64 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC29 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CY01 0800326R CAP.-ELECTRO. 100UF-M 16V
CC30 AA01802R CCC103K50-B-16CT MCH18 CY02 AA01802R CCC103K50-B-16CT MCH18
CC31 0893213R CAP1608CHIP 2200PFKB 50V TAPE CY03 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CC32 AA01141R CERAMIC CAPACITOR(0.1UF 16V) CY04 AA01802R CCC103K50-B-16CT MCH18
CK01 0800355N CAP.ELECTRO. 470UF-M 35V CY05 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CK02 0800355N CAP.ELECTRO. 470UF-M 35V CY06 0893113R CAP 1608CHIP 10PFCCH 50V TAPE
CK03 0880044R CAP.-POLYESTER 0.01UF-KEB 50V
CK04 0880044R CAP.-POLYESTER 0.01UF-KEB 50V
DIODES
CK05 0893201R CAP 1608CHIP 270PFKB 50V TAPE D001 CC01891R SDS511_PF
CK06 0893201R CAP 1608CHIP 270PFKB 50V TAPE D002 2348163M ZENER MTZJ-9.1C TA
CK07 0893201R CAP 1608CHIP 270PFKB 50V TAPE D003 2348163M ZENER MTZJ-9.1C TA
CK08 0893201R CAP 1608CHIP 270PFKB 50V TAPE D004 CC01891R SDS511_PF
CK09 0893201R CAP 1608CHIP 270PFKB 50V TAPE D012 CC01922R SDS142WMF
CK10 0893201R CAP 1608CHIP 270PFKB 50V TAPE D015 CC01922R SDS142WMF
CK11 0893128R CAP 1608CHIP 150PFJCH 50V TAPE D016 CC01922R SDS142WMF
CK12 0893128R CAP 1608CHIP 150PFJCH 50V TAPE D018 CC01922R SDS142WMF
CK13 0893128R CAP 1608CHIP 150PFJCH 50V TAPE D022 CC01922R SDS142WMF
CK14 0893128R CAP 1608CHIP 150PFJCH 50V TAPE D301 2348293M DIODE MTZ-J33CTA
CK15 0893128R CAP 1608CHIP 150PFJCH 50V TAPE D504 CC01922R SDS142WMF
CK16 0893128R CAP 1608CHIP 150PFJCH 50V TAPE D505 CC01922R SDS142WMF
CK17 0880057R CAP.-POLYESTER 0.1UF-KEB 50V D506 CC01922R SDS142WMF
CK18 0880057R CAP.-POLYESTER 0.1UF-KEB 50V D510 2348031M DIO-MTZ-J2.7ATA
CK19 0880057R CAP.-POLYESTER 0.1UF-KEB 50V D511 2348031M DIO-MTZ-J2.7ATA
CK20 0880057R CAP.-POLYESTER 0.1UF-KEB 50V D512 CC01921R SDS142WKF_PF
CX01 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DA01 2337341M DIODE 1SS270A (TP)
CX02 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DA02 2337341M DIODE 1SS270A (TP)
CX03 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DA03 2337341M DIODE 1SS270A (TP)
CX04 AA01121R CERAMIC CAPACITOR(0.47UF 10V) DA04 2337341M DIODE 1SS270A (TP)
CX05 AA00934R CAP. CERAMIC 2012 (2.2UF 10V) DA05 CC01922R SDS142WMF
CX06 AA01802R CCC103K50-B-16CT MCH18 DA11 CC01921R SDS142WKF_PF
CX07 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DA12 CC01921R SDS142WKF_PF
CX08 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V DA13 CC01921R SDS142WKF_PF
CX09 AA01802R CCC103K50-B-16CT MCH18 DA14 CC01921R SDS142WKF_PF
CX10 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DC01 CC01922R SDS142WMF
CX11 AA01802R CCC103K50-B-16CT MCH18 DC02 CC01922R SDS142WMF
CX12 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DC03 CC01922R SDS142WMF
CX13 AA01141R CERAMIC CAPACITOR(0.1UF 16V) DC04 CC01922R SDS142WMF
CX14 AA01113R CCC225K06-B-16CT DC05 CC01922R SDS142WMF
CX15 AA01121R CERAMIC CAPACITOR(0.47UF 10V) DC06 CC01922R SDS142WMF
CX16 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V DC07 CC01922R SDS142WMF
CX17 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V DC08 CC01922R SDS142WMF
DP65
