DP65
PRODUCT SERVICE NOTE:Components marked with a have special characteristics important to safety.Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
158
SYMBOL PART # DESCRIPTION SYMBOL PART # DESCRIPTION
DC09 CC01922R SDS142WMF I309 CK37218R MONO IC TK11150CSCL
DC10 CC01922R SDS142WMF I310 CK50961R SN74CB3T3306DCUR
DC11 CC01922R SDS142WMF I501 CK53531U R2S11008FP
DC12 CC01922R SDS142WMF IA02 CK53441R NJW1173
DC13 CC01922R SDS142WMF IA03 2004752 TA8200AHQ
DC14 CC01891R SDS511_PF IA04 CP05163S IC SI-3090F(LF1111)
DC15 CC01921R SDS142WKF_PF IC01 CK53509R MM1665AHBE
DC16 CC01911R SDS142WAF_PF IK01 CZ01251 STK394-710
DC17 2348212M ZENER DIODE MTZ-J15B IK02 CZ01251 STK394-710
DC18 2348081M DIODE MTZ-J4.3ATA IK03 CK38436R MONOLITHIC IC BD5245G
DC19 CC01891R SDS511_PF IX01 CK38711U IC TA1360AFG(HIT)
DC20 CC01922R SDS142WMF IX02 CP05163S IC SI-3090F(LF1111)
DC21 CC01891R SDS511_PF
DC22 2348002M DIODE MTZ-J2.0BT
COILS
DC23 CC01891R SDS511_PF L001 BA00894R LBC2518 CHIP COIL 100UH
DC24 CC01891R SDS511_PF L002 BH00697R FILTER COIL 100UH
DC25 CC01891R SDS511_PF L004 BH00697R FILTER COIL 100UH
DC26 CC01891R SDS511_PF L005 BH00697R FILTER COIL 100UH
DC27 CC01891R SDS511_PF L008 BA00894R LBC2518 CHIP COIL 100UH
DC29 2348142M ZENER MTZ-J7.5BTA L305 BA00889R LBC2518 CHIP COIL 22UH
DC30 CC01922R SDS142WMF L306 BA02252R 7E06NG TYPE POWER INDUCTOR 6.8
DC31 2348212M ZENER DIODE MTZ-J15B L307 BA02252R 7E06NG TYPE POWER INDUCTOR 6.8
DC32 CC01922R SDS142WMF L308 BA00894R LBC2518 CHIP COIL 100UH
DC33 CC01922R SDS142WMF L309 BA00887R LBC2518 CHIP COIL 10UH
DK03 2348303M DIODE MTZ-J 36CTA L310 BA00889R LBC2518 CHIP COIL 22UH
DK04 2348303M DIODE MTZ-J 36CTA L311 BA00887R LBC2518 CHIP COIL 10UH
DK05 2348303M DIODE MTZ-J 36CTA L501 BA00894R LBC2518 CHIP COIL 100UH
DK06 2348303M DIODE MTZ-J 36CTA L502 BA00889R LBC2518 CHIP COIL 22UH
DK07 2348303M DIODE MTZ-J 36CTA L503 BA00889R LBC2518 CHIP COIL 22UH
DK08 2348303M DIODE MTZ-J 36CTA L504 BA00894R LBC2518 CHIP COIL 100UH
DK09 2348303M DIODE MTZ-J 36CTA LA01 BA00894R LBC2518 CHIP COIL 100UH
DK10 2348303M DIODE MTZ-J 36CTA LA02 2125797N FILT.COIL(LHL08 10UH)
DK11 2348303M DIODE MTZ-J 36CTA LC02 2123468M FERRITE BEADS CORE LEAD 0.8MH
DK12 2348303M DIODE MTZ-J 36CTA LC03 2123468M FERRITE BEADS CORE LEAD 0.8MH
DK13 2348303M DIODE MTZ-J 36CTA LC05 2123469M FERRITE BEADS CORE 2.3UH
DK14 2348303M DIODE MTZ-J 36CTA LX01 BH00697R FILTER COIL 100UH
DK15 2348142M ZENER MTZ-J7.5BTA LX02 BH00697R FILTER COIL 100UH
DK16 2348142M ZENER MTZ-J7.5BTA LX03 BH00697R FILTER COIL 100UH
DK17 2348142M ZENER MTZ-J7.5BTA LX04 BH00697R FILTER COIL 100UH
DK18 2348142M ZENER MTZ-J7.5BTA LY01 BA00894R LBC2518 CHIP COIL 100UH
DK19 2348142M ZENER MTZ-J7.5BTA
DK20 2348142M ZENER MTZ-J7.5BTA
TRANSISTORS
DK21 2348142M ZENER MTZ-J7.5BTA Q001 CA02142R TRS.CHIP 2SC5343UFG_PF
DK22 2348142M ZENER MTZ-J7.5BTA Q002 CA02142R TRS.CHIP 2SC5343UFG_PF
DK23 2348142M ZENER MTZ-J7.5BTA Q003 CA02142R TRS.CHIP 2SC5343UFG_PF
DK24 2348142M ZENER MTZ-J7.5BTA Q004 CA02142R TRS.CHIP 2SC5343UFG_PF
DK25 2348142M ZENER MTZ-J7.5BTA Q005 CA02132R TRS.CHIP 2SA1980UFG_PF
DK26 2348142M ZENER MTZ-J7.5BTA Q006 CA02142R TRS.CHIP 2SC5343UFG_PF
DK27 2348142M ZENER MTZ-J7.5BTA Q007 CA02132R TRS.CHIP 2SA1980UFG_PF
DX01 CC01891R SDS511_PF Q008 CA02132R TRS.CHIP 2SA1980UFG_PF
DX02 CC01891R SDS511_PF Q009 CA02142R TRS.CHIP 2SC5343UFG_PF
DX03 CC01921R SDS142WKF_PF Q011 CA02142R TRS.CHIP 2SC5343UFG_PF
DX04 CC01922R SDS142WMF Q012 CA02092R SRC1202EF
DX05 CC01922R SDS142WMF Q013 CA02132R TRS.CHIP 2SA1980UFG_PF
DX06 CC01922R SDS142WMF Q014 CA02142R TRS.CHIP 2SC5343UFG_PF
DX07 CC01891R SDS511_PF Q016 CA02092R SRC1202EF
DX08 CC01922R SDS142WMF Q017 CA02092R SRC1202EF
DY01 CC01922R SDS142WMF Q018 CA02092R SRC1202EF
Q019 CA02132R TRS.CHIP 2SA1980UFG_PF
INTEGRATED CIRCUITS (IC's) Q020 CA02092R SRC1202EF
I001 CK39652R DIGITAL MONOLITHIC IC (BR24L32FJ-WE2) Q021 CA02142R TRS.CHIP 2SC5343UFG_PF
I002 CK50613U M306V7MJ-0555FP Q022 CA02092R SRC1202EF
I003 CK51101R BD87A29FVM Q023 CA02092R SRC1202EF
I004 CK37216R MONO IC TK11133CSCL Q024 CA02092R SRC1202EF
I005 CK50961R SN74CB3T3306DCUR Q025 CA02132R TRS.CHIP 2SA1980UFG_PF
I006 CK50121R IC CD4053BPWR Q026 CA02132R TRS.CHIP 2SA1980UFG_PF
I007 CK51091R SN74LVC1G3157DCKR Q028 CA02092R SRC1202EF
I301 CK51381R NJM4580V-TE1 Q301 CA02142R TRS.CHIP 2SC5343UFG_PF
I302 CK50051R MAX4788EXS-T Q302 CA02091R SRC1204EF_PF
I303 CK53509R MM1665AHBE Q307 CA02132R TRS.CHIP 2SA1980UFG_PF
I304 CK37216R MONO IC TK11133CSCL Q308 CA02142R TRS.CHIP 2SC5343UFG_PF
I305 CK50071R TPS62040DGQR Q309 CA02142R TRS.CHIP 2SC5343UFG_PF
I306 CK50071R TPS62040DGQR Q310 CA02132R TRS.CHIP 2SA1980UFG_PF
I307 CK53474R MM1661JHBE Q311 CA02142R TRS.CHIP 2SC5343UFG_PF
I308 CK37218R MONO IC TK11150CSCL Q501 CA02132R TRS.CHIP 2SA1980UFG_PF
