DP65
PRODUCT SERVICE NOTE:Components marked with a have special characteristics important to safety.Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
SYMBOL PART # DESCRIPTION SYMBOL PART # DESCRIPTION
Q502 CA02132R TRS.CHIP 2SA1980UFG_PF R008 0790033R RES.CHIP 1/16W 470 OHM
Q503 CA02142R TRS.CHIP 2SC5343UFG_PF R009 0790042R RES.CHIP 1/16W 2.2K OHM
Q504 CA00461R TRS.CHIP 2SD2114K 20V TAPE R010 0790042R RES.CHIP 1/16W 2.2K OHM
Q505 CA00461R TRS.CHIP 2SD2114K 20V TAPE R011 0790037R RES.CHIP 1/16W 1.0K OHM
QA03 CA02091R SRC1204EF_PF R012 0790064R RES.CHIP 1/16W 100K OHM
QA04 CA02142R TRS.CHIP 2SC5343UFG_PF R013 0790046R RES.CHIP 1/16W 4.7K OHM
QA05 CA02132R TRS.CHIP 2SA1980UFG_PF R014 0790028R RES.CHIP 1/16W 220 OHM
QA06 CA02142R TRS.CHIP 2SC5343UFG_PF R015 0790051R RES.CHIP 1/16W 10K OHM
QA07 CA02132R TRS.CHIP 2SA1980UFG_PF R016 0790064R RES.CHIP 1/16W 100K OHM
QA08 CA00461R TRS.CHIP 2SD2114K 20V TAPE R017 0790046R RES.CHIP 1/16W 4.7K OHM
QA09 CA00461R TRS.CHIP 2SD2114K 20V TAPE R018 0790024R RES.CHIP 1/16W 100 OHM
QA10 CA02142R TRS.CHIP 2SC5343UFG_PF R019 0790024R RES.CHIP 1/16W 100 OHM
QA11 CA02091R SRC1204EF_PF R020 0790024R RES.CHIP 1/16W 100 OHM
QA12 CA02132R TRS.CHIP 2SA1980UFG_PF R022 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
QA14 CA02142R TRS.CHIP 2SC5343UFG_PF R023 0790051R RES.CHIP 1/16W 10K OHM
QC01 CA02142R TRS.CHIP 2SC5343UFG_PF R024 0790047R RES.CHIP 1/16W 5.6K OHM
QC02 CA02132R TRS.CHIP 2SA1980UFG_PF R025 0790059R RES.CHIP 1/16W 47K OHM
QC03 CA02091R SRC1204EF_PF R026 0790051R RES.CHIP 1/16W 10K OHM
QC04 CA02132R TRS.CHIP 2SA1980UFG_PF R027 0790039R RES.CHIP 1/16W 1.5K OHM
QC05 CA02142R TRS.CHIP 2SC5343UFG_PF R028 0790051R RES.CHIP 1/16W 10K OHM
QC06 CA02142R TRS.CHIP 2SC5343UFG_PF R029 0790047R RES.CHIP 1/16W 5.6K OHM
QC07 CA02132R TRS.CHIP 2SA1980UFG_PF R030 0790064R RES.CHIP 1/16W 100K OHM
QC08 CA02142R TRS.CHIP 2SC5343UFG_PF R031 0790052R RES.CHIP 1/16W 12K OHM
QC09 CA02142R TRS.CHIP 2SC5343UFG_PF R032 0790047R RES.CHIP 1/16W 5.6K OHM
QC10 CA02142R TRS.CHIP 2SC5343UFG_PF R033 0790024R RES.CHIP 1/16W 100 OHM
QC11 CA02142R TRS.CHIP 2SC5343UFG_PF R034 0790046R RES.CHIP 1/16W 4.7K OHM
QC12 CA02132R TRS.CHIP 2SA1980UFG_PF R035 0790058R RES.CHIP 1/16W 39K OHM
QC13 CA02142R TRS.CHIP 2SC5343UFG_PF R036 0790059R RES.CHIP 1/16W 47K OHM
QC14 CA02132R TRS.CHIP 2SA1980UFG_PF R037 0790059R RES.CHIP 1/16W 47K OHM
QC15 CA02132R TRS.CHIP 2SA1980UFG_PF R038 0790024R RES.CHIP 1/16W 100 OHM
QC16 2312171F TRS. 2SC3852(LF619) R039 0790044R RES.CHIP 1/16W 3.3K OHM
QC17 CA02142R TRS.CHIP 2SC5343UFG_PF R040 0790037R RES.CHIP 1/16W 1.0K OHM
QC21 CA02142R TRS.CHIP 2SC5343UFG_PF R041 0790057R RES.CHIP 1/16W 33K OHM
QC22 CA02091R SRC1204EF_PF R042 0790051R RES.CHIP 1/16W 10K OHM
QC23 CA02091R SRC1204EF_PF R043 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
QC24 CA02142R TRS.CHIP 2SC5343UFG_PF R044 0790051R RES.CHIP 1/16W 10K OHM
QX01 CA02142R TRS.CHIP 2SC5343UFG_PF R045 0790059R RES.CHIP 1/16W 47K OHM
QX02 CA02132R TRS.CHIP 2SA1980UFG_PF R046 0790051R RES.CHIP 1/16W 10K OHM
QX03 CA02142R TRS.CHIP 2SC5343UFG_PF R047 0790047R RES.CHIP 1/16W 5.6K OHM
QX04 CA02132R TRS.CHIP 2SA1980UFG_PF R048 0790037R RES.CHIP 1/16W 1.0K OHM
QX05 CA02142R TRS.CHIP 2SC5343UFG_PF R049 0790051R RES.CHIP 1/16W 10K OHM
QX06 CA02142R TRS.CHIP 2SC5343UFG_PF R050 0790051R RES.CHIP 1/16W 10K OHM
QX09 CA02132R TRS.CHIP 2SA1980UFG_PF R051 0790024R RES.CHIP 1/16W 100 OHM
QX10 CA02132R TRS.CHIP 2SA1980UFG_PF R053 0790024R RES.CHIP 1/16W 100 OHM
QX11 CA02132R TRS.CHIP 2SA1980UFG_PF R054 0790031R RES.CHIP 1/16W 330 OHM
QX12 CA02142R TRS.CHIP 2SC5343UFG_PF R055 0790042R RES.CHIP 1/16W 2.2K OHM
QX13 CA02142R TRS.CHIP 2SC5343UFG_PF R056 0790024R RES.CHIP 1/16W 100 OHM
QX14 CA02132R TRS.CHIP 2SA1980UFG_PF R057 0790024R RES.CHIP 1/16W 100 OHM
QX15 CA02142R TRS.CHIP 2SC5343UFG_PF R058 0790024R RES.CHIP 1/16W 100 OHM
QX16 CA02142R TRS.CHIP 2SC5343UFG_PF R059 0790024R RES.CHIP 1/16W 100 OHM
QX17 CA02132R TRS.CHIP 2SA1980UFG_PF R060 0790046R RES.CHIP 1/16W 4.7K OHM
QX18 CA02132R TRS.CHIP 2SA1980UFG_PF R061 0790037R RES.CHIP 1/16W 1.0K OHM
QX19 CA02132R TRS.CHIP 2SA1980UFG_PF R062 0790037R RES.CHIP 1/16W 1.0K OHM
QX21 CF02981R 2SC5343YT_PF R065 0790037R RES.CHIP 1/16W 1.0K OHM
QX22 CA02132R TRS.CHIP 2SA1980UFG_PF R066 0790024R RES.CHIP 1/16W 100 OHM
QX23 CA02132R TRS.CHIP 2SA1980UFG_PF R067 0790037R RES.CHIP 1/16W 1.0K OHM
QX24 CA02132R TRS.CHIP 2SA1980UFG_PF R068 0790037R RES.CHIP 1/16W 1.0K OHM
QX27 CA02132R TRS.CHIP 2SA1980UFG_PF R069 0790037R RES.CHIP 1/16W 1.0K OHM
QX28 CF02991R 2SA1979YT_PF R070 0790051R RES.CHIP 1/16W 10K OHM
QX31 CA02132R TRS.CHIP 2SA1980UFG_PF R071 0790051R RES.CHIP 1/16W 10K OHM
QX32 CF02991R 2SA1979YT_PF R073 0790052R RES.CHIP 1/16W 12K OHM
QX35 CA02132R TRS.CHIP 2SA1980UFG_PF R074 0790055R RES.CHIP 1/16W 22K OHM
QX36 CF02991R 2SA1979YT_PF R075 0790052R RES.CHIP 1/16W 12K OHM
QY01 CA02142R TRS.CHIP 2SC5343UFG_PF R076 0790037R RES.CHIP 1/16W 1.0K OHM
QY02 CA02142R TRS.CHIP 2SC5343UFG_PF R077 0790051R RES.CHIP 1/16W 10K OHM
QY03 CA02142R TRS.CHIP 2SC5343UFG_PF R078 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
QY04 CA02142R TRS.CHIP 2SC5343UFG_PF R080 0790037R RES.CHIP 1/16W 1.0K OHM
QY05 CA02132R TRS.CHIP 2SA1980UFG_PF R081 0790046R RES.CHIP 1/16W 4.7K OHM
QY06 CF02991R 2SA1979YT_PF R082 0790024R RES.CHIP 1/16W 100 OHM
R083 0790024R RES.CHIP 1/16W 100 OHM
RESISTORS R084 0790024R RES.CHIP 1/16W 100 OHM
R001 0790051R RES.CHIP 1/16W 10K OHM R085 0790024R RES.CHIP 1/16W 100 OHM
R003 0790051R RES.CHIP 1/16W 10K OHM R086 0790037R RES.CHIP 1/16W 1.0K OHM
R006 0790051R RES.CHIP 1/16W 10K OHM R087 0790037R RES.CHIP 1/16W 1.0K OHM
R007 0790033R RES.CHIP 1/16W 470 OHM R088 0790037R RES.CHIP 1/16W 1.0K OHM
