160
DP65
PRODUCT SERVICE NOTE:Components marked with a have special characteristics important to safety.Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
SYMBOL PART # DESCRIPTION SYMBOL PART # DESCRIPTION
R089 0790037R RES.CHIP 1/16W 1.0K OHM R189 0790024R RES.CHIP 1/16W 100 OHM
R090 0790037R RES.CHIP 1/16W 1.0K OHM R190 0790037R RES.CHIP 1/16W 1.0K OHM
R091 0790037R RES.CHIP 1/16W 1.0K OHM R191 0790051R RES.CHIP 1/16W 10K OHM
R092 0790024R RES.CHIP 1/16W 100 OHM R192 0790024R RES.CHIP 1/16W 100 OHM
R093 0790024R RES.CHIP 1/16W 100 OHM R193 0790024R RES.CHIP 1/16W 100 OHM
R094 0790055R RES.CHIP 1/16W 22K OHM R194 0790024R RES.CHIP 1/16W 100 OHM
R095 0790037R RES.CHIP 1/16W 1.0K OHM R195 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R096 0790037R RES.CHIP 1/16W 1.0K OHM R196 0790051R RES.CHIP 1/16W 10K OHM
R098 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R197 0790051R RES.CHIP 1/16W 10K OHM
R099 0790042R RES.CHIP 1/16W 2.2K OHM R198 0790024R RES.CHIP 1/16W 100 OHM
R100 0790024R RES.CHIP 1/16W 100 OHM R199 0790024R RES.CHIP 1/16W 100 OHM
R101 AQ00177R RES.CHIP 1/16W 240 OHM TAPE R203 0790024R RES.CHIP 1/16W 100 OHM
R102 AQ00176R RES.CHIP 1/16W 220 OHM TAPE R204 0790051R RES.CHIP 1/16W 10K OHM
R103 0790077R RES.CHIP 1/16W 1.0M OHM R205 0790051R RES.CHIP 1/16W 10K OHM
R104 0790033R RES.CHIP 1/16W 470 OHM R206 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R105 0790077R RES.CHIP 1/16W 1.0M OHM R207 0790051R RES.CHIP 1/16W 10K OHM
R106 0790059R RES.CHIP 1/16W 47K OHM R208 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R107 0790059R RES.CHIP 1/16W 47K OHM R209 0790037R RES.CHIP 1/16W 1.0K OHM
R108 0790059R RES.CHIP 1/16W 47K OHM R210 0790024R RES.CHIP 1/16W 100 OHM
R109 0790037R RES.CHIP 1/16W 1.0K OHM R211 0790024R RES.CHIP 1/16W 100 OHM
R110 0790037R RES.CHIP 1/16W 1.0K OHM R212 0790037R RES.CHIP 1/16W 1.0K OHM
R111 0790037R RES.CHIP 1/16W 1.0K OHM R213 0790051R RES.CHIP 1/16W 10K OHM
R113 0790024R RES.CHIP 1/16W 100 OHM R214 0790051R RES.CHIP 1/16W 10K OHM
R114 0790024R RES.CHIP 1/16W 100 OHM R215 0790024R RES.CHIP 1/16W 100 OHM
R115 0790024R RES.CHIP 1/16W 100 OHM R216 0790051R RES.CHIP 1/16W 10K OHM
R116 0790024R RES.CHIP 1/16W 100 OHM R217 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R117 0790024R RES.CHIP 1/16W 100 OHM R218 0790051R RES.CHIP 1/16W 10K OHM
R118 0790024R RES.CHIP 1/16W 100 OHM R219 0790037R RES.CHIP 1/16W 1.0K OHM
R119 0790024R RES.CHIP 1/16W 100 OHM R220 0790024R RES.CHIP 1/16W 100 OHM
R120 0790024R RES.CHIP 1/16W 100 OHM R221 0790037R RES.CHIP 1/16W 1.0K OHM
R121 0790024R RES.CHIP 1/16W 100 OHM R222 0790051R RES.CHIP 1/16W 10K OHM
R127 0790037R RES.CHIP 1/16W 1.0K OHM R223 0790037R RES.CHIP 1/16W 1.0K OHM
R128 0790037R RES.CHIP 1/16W 1.0K OHM R224 0790059R RES.CHIP 1/16W 47K OHM
R130 0790037R RES.CHIP 1/16W 1.0K OHM R226 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R131 0790042R RES.CHIP 1/16W 2.2K OHM R227 0790037R RES.CHIP 1/16W 1.0K OHM
R132 0790037R RES.CHIP 1/16W 1.0K OHM R230 0790055R RES.CHIP 1/16W 22K OHM
R133 0790037R RES.CHIP 1/16W 1.0K OHM R234 0790051R RES.CHIP 1/16W 10K OHM
R134 0790033R RES.CHIP 1/16W 470 OHM R239 0790037R RES.CHIP 1/16W 1.0K OHM
R135 0790047R RES.CHIP 1/16W 5.6K OHM R244 0790051R RES.CHIP 1/16W 10K OHM
R138 0790055R RES.CHIP 1/16W 22K OHM R245 0790059R RES.CHIP 1/16W 47K OHM
R139 0790037R RES.CHIP 1/16W 1.0K OHM R304 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R141 0790037R RES.CHIP 1/16W 1.0K OHM R305 0790037R RES.CHIP 1/16W 1.0K OHM
R142 0790024R RES.CHIP 1/16W 100 OHM R306 0790037R RES.CHIP 1/16W 1.0K OHM
R144 0790037R RES.CHIP 1/16W 1.0K OHM R308 0790059R RES.CHIP 1/16W 47K OHM
R145 0790037R RES.CHIP 1/16W 1.0K OHM R311 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R146 0790024R RES.CHIP 1/16W 100 OHM R312 0790037R RES.CHIP 1/16W 1.0K OHM
R147 0790024R RES.CHIP 1/16W 100 OHM R313 0790051R RES.CHIP 1/16W 10K OHM
R148 0790024R RES.CHIP 1/16W 100 OHM R314 0790051R RES.CHIP 1/16W 10K OHM
R149 0790047R RES.CHIP 1/16W 5.6K OHM R315 0790037R RES.CHIP 1/16W 1.0K OHM
R150 0790028R RES.CHIP 1/16W 220 OHM R316 0790042R RES.CHIP 1/16W 2.2K OHM
R151 0790024R RES.CHIP 1/16W 100 OHM R324 0790051R RES.CHIP 1/16W 10K OHM
R152 0790047R RES.CHIP 1/16W 5.6K OHM R326 0790024R RES.CHIP 1/16W 100 OHM
R154 0790037R RES.CHIP 1/16W 1.0K OHM R330 0790024R RES.CHIP 1/16W 100 OHM
R155 0790024R RES.CHIP 1/16W 100 OHM R331 0790024R RES.CHIP 1/16W 100 OHM
R158 AQ00344R RES.CHIP 1/16W 100 OHM TAPE R335 0790024R RES.CHIP 1/16W 100 OHM
R159 AQ00344R RES.CHIP 1/16W 100 OHM TAPE R336 0790024R RES.CHIP 1/16W 100 OHM
R163 0790024R RES.CHIP 1/16W 100 OHM R337 0790024R RES.CHIP 1/16W 100 OHM
R164 0790051R RES.CHIP 1/16W 10K OHM R338 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R165 0790051R RES.CHIP 1/16W 10K OHM R339 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R168 0790051R RES.CHIP 1/16W 10K OHM R340 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R170 AQ00344R RES.CHIP 1/16W 100 OHM TAPE R341 0790064R RES.CHIP 1/16W 100K OHM
R171 0790051R RES.CHIP 1/16W 10K OHM R342 0790064R RES.CHIP 1/16W 100K OHM
R172 AQ00344R RES.CHIP 1/16W 100 OHM TAPE R344 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R173 AQ00344R RES.CHIP 1/16W 100 OHM TAPE R345 0790061R RES.CHIP 1/16W 56K OHM
R176 0790024R RES.CHIP 1/16W 100 OHM R346 0790024R RES.CHIP 1/16W 100 OHM
R177 0790024R RES.CHIP 1/16W 100 OHM R347 0790024R RES.CHIP 1/16W 100 OHM
R178 0790037R RES.CHIP 1/16W 1.0K OHM R348 0790064R RES.CHIP 1/16W 100K OHM
R179 0790051R RES.CHIP 1/16W 10K OHM R349 0790039R RES.CHIP 1/16W 1.5K OHM
R180 0790051R RES.CHIP 1/16W 10K OHM R350 0790039R RES.CHIP 1/16W 1.5K OHM
R181 0790051R RES.CHIP 1/16W 10K OHM R351 0790024R RES.CHIP 1/16W 100 OHM
R182 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R352 0790063R RES.CHIP 1/16W 82K OHM
R183 0790024R RES.CHIP 1/16W 100 OHM R353 0790024R RES.CHIP 1/16W 100 OHM
R184 0790033R RES.CHIP 1/16W 470 OHM R354 0790054R RES.CHIP 1/16W 18K OHM
R186 0790059R RES.CHIP 1/16W 47K OHM R355 AQ00234R RES.CHIP 1/16W 33K OHM TAPE
R187 0790024R RES.CHIP 1/16W 100 OHM R356 AQ00261R RES.CHIP 1/16W 330K OHM TAPE
