Hitachi 57F59A - Page 162

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
161
SYMBOL PART # DESCRIPTION SYMBOL PART # DESCRIPTION
R357 AQ00245R RES.CHIP 1/16W 82K OHM TAPE R558 0790024R RES.CHIP 1/16W 100 OHM
R358 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R559 AQ00163R RES.CHIP 1/16W 68 OHM TAPE
R359 0790055R RES.CHIP 1/16W 22K OHM R560 AQ00163R RES.CHIP 1/16W 68 OHM TAPE
R360 0790041R RES.CHIP 1/16W 1.8K OHM R561 AQ00163R RES.CHIP 1/16W 68 OHM TAPE
R361 0790059R RES.CHIP 1/16W 47K OHM R562 0790024R RES.CHIP 1/16W 100 OHM
R362 0790041R RES.CHIP 1/16W 1.8K OHM R563 0790064R RES.CHIP 1/16W 100K OHM
R363 AQ00217R RES.CHIP 1/16W 7.5K OHM TAPE R564 0790064R RES.CHIP 1/16W 100K OHM
R364 AQ00229R RES.CHIP 1/16W 22K OHM TAPE R565 0790064R RES.CHIP 1/16W 100K OHM
R365 0790051R RES.CHIP 1/16W 10K OHM R566 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R367 0790037R RES.CHIP 1/16W 1.0K OHM R567 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R368 0790037R RES.CHIP 1/16W 1.0K OHM R568 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R369 0790051R RES.CHIP 1/16W 10K OHM R569 0790064R RES.CHIP 1/16W 100K OHM
R370 0790063R RES.CHIP 1/16W 82K OHM R570 0790064R RES.CHIP 1/16W 100K OHM
R371 0790063R RES.CHIP 1/16W 82K OHM R571 0790037R RES.CHIP 1/16W 1.0K OHM
R372 AQ00217R RES.CHIP 1/16W 7.5K OHM TAPE R572 0790037R RES.CHIP 1/16W 1.0K OHM
R373 AQ00232R RES.CHIP 1/16W 27K OHM TAPE R573 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R374 AQ00232R RES.CHIP 1/16W 27K OHM TAPE R574 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R375 AQ00232R RES.CHIP 1/16W 27K OHM TAPE R575 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R376 AQ00232R RES.CHIP 1/16W 27K OHM TAPE R576 0790064R RES.CHIP 1/16W 100K OHM
R377 0790051R RES.CHIP 1/16W 10K OHM R577 0790037R RES.CHIP 1/16W 1.0K OHM
R378 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R578 0790037R RES.CHIP 1/16W 1.0K OHM
R380 0790063R RES.CHIP 1/16W 82K OHM R579 0790064R RES.CHIP 1/16W 100K OHM
R381 0790063R RES.CHIP 1/16W 82K OHM R580 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R383 0790051R RES.CHIP 1/16W 10K OHM R581 0790037R RES.CHIP 1/16W 1.0K OHM
R392 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R582 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R393 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R583 0790037R RES.CHIP 1/16W 1.0K OHM
R394 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R584 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R395 0790063R RES.CHIP 1/16W 82K OHM R585 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R396 0790063R RES.CHIP 1/16W 82K OHM R586 0790024R RES.CHIP 1/16W 100 OHM
R397 AT03206S METAL OX. 4.7OHM 1W R587 0790064R RES.CHIP 1/16W 100K OHM
R398 AT03844M 10.0OHM 1/2W RDS50 CARBON FILM RESISTOR R588 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R504 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R589 0790064R RES.CHIP 1/16W 100K OHM
R505 0790037R RES.CHIP 1/16W 1.0K OHM R590 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE
R506 0790037R RES.CHIP 1/16W 1.0K OHM R591 0790037R RES.CHIP 1/16W 1.0K OHM
R507 0790024R RES.CHIP 1/16W 100 OHM R592 0790037R RES.CHIP 1/16W 1.0K OHM
R508 0790024R RES.CHIP 1/16W 100 OHM R593 0790064R RES.CHIP 1/16W 100K OHM
R509 0790024R RES.CHIP 1/16W 100 OHM R594 0790024R RES.CHIP 1/16W 100 OHM
R510 0790024R RES.CHIP 1/16W 100 OHM R595 0790064R RES.CHIP 1/16W 100K OHM
R511 0790024R RES.CHIP 1/16W 100 OHM R596 0790037R RES.CHIP 1/16W 1.0K OHM
R512 0790042R RES.CHIP 1/16W 2.2K OHM R597 0790024R RES.CHIP 1/16W 100 OHM
R513 0790042R RES.CHIP 1/16W 2.2K OHM R598 0790037R RES.CHIP 1/16W 1.0K OHM
R514 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R599 0790037R RES.CHIP 1/16W 1.0K OHM
R515 0790024R RES.CHIP 1/16W 100 OHM R5A0 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R516 0790024R RES.CHIP 1/16W 100 OHM R5A1 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R517 0790037R RES.CHIP 1/16W 1.0K OHM R5A2 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R518 0790037R RES.CHIP 1/16W 1.0K OHM R5A3 0790059R RES.CHIP 1/16W 47K OHM
R519 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5A4 0790059R RES.CHIP 1/16W 47K OHM
R520 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5A5 0790037R RES.CHIP 1/16W 1.0K OHM
R531 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5A6 0790051R RES.CHIP 1/16W 10K OHM
R532 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5A7 0790064R RES.CHIP 1/16W 100K OHM
R533 0790024R RES.CHIP 1/16W 100 OHM R5A8 0790064R RES.CHIP 1/16W 100K OHM
R534 0790024R RES.CHIP 1/16W 100 OHM R5A9 0790064R RES.CHIP 1/16W 100K OHM
R535 0790018R RES.CHIP 1/16W 39 OHM R5C0 0790064R RES.CHIP 1/16W 100K OHM
R536 0790018R RES.CHIP 1/16W 39 OHM R5C1 0790051R RES.CHIP 1/16W 10K OHM
R537 0790018R RES.CHIP 1/16W 39 OHM R5C2 0790051R RES.CHIP 1/16W 10K OHM
R538 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5C3 0790053R RES.CHIP 1/16W 15K OHM
R539 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5C4 0790064R RES.CHIP 1/16W 100K OHM
R540 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 R5C5 0790064R RES.CHIP 1/16W 100K OHM
R541 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE R5C6 0790037R RES.CHIP 1/16W 1.0K OHM
R542 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE R5C7 0790037R RES.CHIP 1/16W 1.0K OHM
R543 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE R5C8 0790063R RES.CHIP 1/16W 82K OHM
R544 0790037R RES.CHIP 1/16W 1.0K OHM R5C9 0790063R RES.CHIP 1/16W 82K OHM
R545 0790037R RES.CHIP 1/16W 1.0K OHM R5E0 0790028R RES.CHIP 1/16W 220 OHM
R546 0790024R RES.CHIP 1/16W 100 OHM R5E1 0790028R RES.CHIP 1/16W 220 OHM
R547 0790024R RES.CHIP 1/16W 100 OHM R5E2 0790051R RES.CHIP 1/16W 10K OHM
R548 0790024R RES.CHIP 1/16W 100 OHM R5E3 0790051R RES.CHIP 1/16W 10K OHM
R549 0790037R RES.CHIP 1/16W 1.0K OHM R5E7 0790037R RES.CHIP 1/16W 1.0K OHM
R550 0790024R RES.CHIP 1/16W 100 OHM R5E8 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R551 0790037R RES.CHIP 1/16W 1.0K OHM R5E9 0790037R RES.CHIP 1/16W 1.0K OHM
R552 0790024R RES.CHIP 1/16W 100 OHM R5F0 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R553 0790024R RES.CHIP 1/16W 100 OHM R5F1 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R554 0790024R RES.CHIP 1/16W 100 OHM R5F3 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R555 0790037R RES.CHIP 1/16W 1.0K OHM R5F5 0790051R RES.CHIP 1/16W 10K OHM
R556 0790024R RES.CHIP 1/16W 100 OHM RA01 0790028R RES.CHIP 1/16W 220 OHM
R557 0790037R RES.CHIP 1/16W 1.0K OHM RA03 0790037R RES.CHIP 1/16W 1.0K OHM
DP65
