HMCS44C,HMCS44CL-------------------------------------------------------
• SUBROUTINE
JUMP
There are
two
types
of
subroutine jumps. They are explained
in the
following
paragraphs.
• CAL
By
CAL instruction, subroutine jump to an address
in
the
Subroutine
Page.
The Subroutine Page
is
0
page.
The address next to CAL instruction address
is
pushed onto
the stack STl and the contents
of
the stacks
STl,
ST2
and
ST3
are pushed onto the stacks ST2,
ST3
and
ST4
respectively
as
shown
in
Figure
9.
06
0,
ROM
: CAL: I : :
~
: : I
1f11rJJJJJJ
PC
I :
Pa?8
Par~
I
~d~r8ss
Part
I
l l l ! l ! ! l l l !
(PC
+
1)
snl
: : : : : : : : : : I
'+ii""i"
ST21 : : : : : : : : : : I
'iiiiiillii
ST3\:
::::::::
I
"'i""'"
ST41
:::::::::
I
Figure 9 Subroutine
Jump
Stacking Order
The page part
of
the program counter
is
o.
The lower 6 bits
(operand a, 0
6
to 01)
of
the
ROM
Object Code
is
transferred to
the address part of the program counter.
The HMCS44C has 4 levels
of
stack (STl, ST2,
ST3
and
ST4)
which
allows the programmer
to
use
up
to 4 levels
of
sub-
routine jumps (including interrupts).
CAL
is
a conditional instruction and executed only when the
48
Status FIF
is
"1".
If
the Status
FIF
is
"0",
it
is
skipped and the
Status
FIF
changes to "1
".
•
CALL
By
CALL instruction, subroutine jump to an address in any
page.
Subroutine jump to any address can be implemented
by
the
subroutine jump to the
page
specified
by
LPU instruction.
This instruction
is
a macro instruction
of
LPU and CAL in-
structions, which
is
divided into
two
instructions
as
follows.
CALL a -
b-LPU
a
< Subroutine jump to b address on a page> CAL b
CALL instruction
is
conditional because
of
characteristics
of
LPU and CAL instructions and
is
executed when the Status
FIF
is
"1".
Ifthe
Status F
IF
is
"0",
it
is
skipped and the Status F
IF
changes to
"1".
•
RAM
RAM
is
a memory used for storing data and saving the con-
tents
of
the registers. Its capacity
is
160
digits (640 bits) where
one digit consists
of
4 bits.
Addressing
of
RAM
is
performed
by
a matrix
of
the
file
No.
and the digit No.
The
file
No.
is
set
in
the X register and the digit
No.
in
the Y
register
for
reading, writing or testing.
Specific
digits
in
RAM can
be addressed not
via
the X register and Y register. These digits
are called "Memory Register (MR)", 0
to
15
(16
digits in all).
The memory register can be exchanged
with
the accumulator
by
XAMR instruction.
The RAM address space
is
shown
in
Figure
10.
In an instruction
in
which reading from RAM and writing to
RAM coexist (exchange between RAM and the register), reading
precedes writing and the write data does not affect the read data.
The RAM bit manipulation instruction enables any addressed
RAM bit to be set, reset or tested. The bit assignment
is
speci-
fied
by
the operand n
of
the instruction.
The bit test makes the Status F
IF
"1"
and makes it
"0"
when the assigned bit
is
"0".
Correspondence between the RAM bit and the operand n
is
shown
in
Figure
11.
