Hitachi AX-M76E - Control Locations; The CD Player; The Amplifier

The Amplier
1. Display Lens
2. AC Power Cord
3. Control Cable Connector
4. Left & Right Speaker Output Terminals
Control Locations
The CD Player
1. Standby
2. USB Port
3. Remote Sensor
4. VFD(Vacuum Fluorescent Display) Display Lens
5. Function
6. Preset Equalizer
7. Volume Control Knob
8. Disc Door
9. Previous/Search Backward
Channel Select Backward – PRESET
10. Next/Search Forward
Channel Select Forward PRESET +
11. Play/Pause
Tuning Backward – TUNING
12. Stop
Tuning Forward TUNING +
13. Mode
Stereo/MONO Select
14. Open/Close
15. Control Cable Connector
16. Line Output Terminals (L&R)
17. AUX Input Terminals (L&R)
18. FM Aerial Socket
