80
Slide Compound Saw Parts List
ITEM NO. DESCRIPTION ITEM NO. DESCRIPTION
1 MACHINE SCREW M6 × 20 45 STEEL BALL D12.7
2 TABLE INSERT 46 LINER
3 MACHINE SCREW M4 × 8 47 FENCE(A)
4 BOLT WASHER M4 49 SET PIN(A)
5 INDICATOR (B) 50 O-RING(P-9)
6 NYLOCK BOLT M8 × 25 51 HINGE ASS’Y(INCLUD.61A)
7 INDICATOR (C) 52 GRIP
8 NYLOCK BOLT M8 × 40 54 NYLON CLIP
9 TURN TABLE 55 BOLT WASHER M4
10 VISE ASS’Y (INCLUD.11-18) 56 MACHINE SCREW M4 × 12
11 KNOB BOLT M10 57
MACHINE SCREW (W/WASHERS) M5 × 25
12 KNOB BOLT M6 × 11 58 CORD
13 SCREW HOLDER 60 ROLL PIN D6 × 40
14 COLLAR 61 SUPPORT
15 VISE PLATE 6 MACHINE SCREW M4 × 12
16 WASHER 63 PACKING COVER
17 HEX.SOCKET HD.BOLT M5 × 10(10PCS.) 64 FELT
18 VISE SHAFT 65 BALL BUSHING
19 BOLT (W/WASHERS) M8 × 5(BLACK) 66 HEX.SOCKET SET SCREW M8 × 8
20 KNOB BOLT M8 × 20 67 BEARING LOCK
21 FENCE (B) 68 HOLDER (A)
22 HOLDER(B) 69 KNOB BOLT M8 × 20
23 BASE ASS’Y (INCLUD.24,26-28,191) 70 LOCK SPRING
24 BOLT M6 × 25 71 HEX.SOCKET SET SCREW M8 × 16
26 BASE RUBBER 72 LOCK NUT M8
27 BOLT WASHER M5 73 BUSHING
28 MACHINE SCREW M5 × 20 75 BOLT WASHER M4
29 SHAFT (A) 76 CAUTION LABEL (A)
30 SPRING WASHER M8 77 HINGE SHAFT
31 WASHER (R) 78 BOLT WASHER M16
32 SPRING (E) 79 SPRING (B)
33 WASHER (G) 80 GRIP (B)
34 MACHINE SCREW M4 × 8 81 CLUTCH SCREW
35 BOLT WASHER M4 82 CLUTCH SPRING
36 INDICATOR 83 CLAMP LEVER
37 BOLT WASHER M4 84 BOLT (LEFT HAND)M12 × 165
38 SPACER 85 THRUST BEARING (51101)
39 BOLT WASHER M4 86 GRIP
40 MACHINE SCREW M4 × 12 87 SET PIN
41 SIDE HANDLE 88 SCREW HOLDER
42 SHAFT 89 SHAFT (B)
43
RETAINING RING (E-TYPE) FOR D7 SHAFT
90 WASHER
44 SPRING (D) 91
MACHINE SCREW (W/WASHERS) M5 × 16
