--- 14 ---
(6) Removal of the Base Ass'y [40]
Extract the Roll Pin D6 x 50 [46] that connects the Base Ass'y [40] and the Housing [34]. Remove the Base
Ass'y [40].
Fig. 5
[34]
[46]
[40]
