5. SPECIFICATIONS
Type of motor
Cutting depth
at 90û
Type of switch
at 45û
Rotation speed
Model
Saw blade diameter
Type of handle
Enclosure
Lower guard
Charger
No-load
Housing, handle cover
Saw cover
0 --- 40 mm (0 --- 1-9/16")
0 --- 57 mm (0 --- 2-1/4")
D type
Trigger switch (automatic return type with switch-lock)
DC magnet motor
165 mm (6-1/2")
C 18DL
Magnesium
ABS resin
3,400/min.
Glassfiber reinforced polycarbonate resin
Polycarbonate
Current (A)
4.5 A
Battery
Glassfiber reinforced polyamide resin
Sealed cylindrical lithium-ion storage battery
Nominal voltage
•••••••••••••••
DC 18 V
Nominal life
•••••••••••••••••••••
Charging/discharging: Approx. 1,500 times
Nominal capacity
•••••••••••••
3.0 Ah
Overcharge protection system:
(1) Battery voltage detection ( -- V system) for Ni-Cd battery
Battery temperature detection (dT/dt system) for Ni-MH and SUPER Ni-MH batteries
(2) Battery surface temperature detection (thermistor)
(3) 120-minute timer
(4) Stop current detection (Li-ion batteries)
Power input: 95 W
Charging time: Approx. 45 minutes [for type EBM 1830 battery at 20ûC (68ûF)]
Operable ambient temperature range: 0 ûC --- 50ûC (32ûF --- 122ûF)
Indication method of battery charging function:
Battery
(Type EBM 1830)
Charger
(Model UC 18YRL)
NOTE: During standby for cooling battery, the Model UC 18YRL cools the overheated battery by
cooling fan.
Weight
Main body (including battery) ............... 3.2 kg (7.1 lbs.)
Charger unit (including cord) ................ 0.6 kg (1.3 lbs.)
Main body, charger, case and other
standard accessories ............................ 8.0 kg (17.8 lbs.)
Net
Gross
Standard accessories
Charger (UC 18YRL) .................................................. 1
Saw blade ................................................................... 1
Box wrench ................................................................. 1
Guide .......................................................................... 1
Plastic tool case .......................................................... 1
Indication of the pilot lamp
Charge status
lamp (Red)
Overheat lamp
(Green)
Before
charging
While
charging
Overheat
standby
Charging
impossible
Charging
completed
Blinks
Lights
Flickers
Blinks
Lights
0.5 sec. ON 0.5 sec. OFF
Stays ON continuously
Stays ON continuously
Malfunction in the battery
or the charger.
Battery overheated.
Unable to charge.
(Charging will commence
when the battery is cooled.)
0.5 sec. ON 0.5 sec. OFF
0.1 sec. ON 0.1 sec. OFF
To Next Page
