(6) Internal wire arrangement (See Figs. from 7 to 10.):
Connect internal wires as illustrated in Figs. from 7 to 10.
At this time, ensure that none of the wires are pinched between components during reassembly.
A. Model C 7SB2
For the U.S.A.
Black
Red
White
Black
Fig. 7
For AUS/GBR (110 V)
Fig. 8
