Hitachi CJ 14DSL Technical Data And Service Manual

-5-
(Superior specifications:
)
1. Specification comparisons
Maker HITACHI
Model name CJ 18DSL CJ 18DL
C
Wood 135 mm (5-5/16”) 135 mm (5-5/16”) 135 mm (5-5/16”)
Cutting
capacity
Mild steel 10 mm (3/8”) 10 mm (3/8”) 10 mm (3/8”)
No-load speed 0 to 2,400 min
-1
0 to 2,400 min
-1
0 to 2,600 min
-1
Min. cutting radius 25 mm (1”) 25 mm (1”) Not indicated
Length of stroke 26 mm (1”) 26 mm (1”) 26 mm (1”)
Max. cutting angle 45° (right and left) 45° (right and left) 45° (right and left)
LED light White LED White LED White LED
Tool-less blade attachment Provided Provided Provided
Soft grip handle Provided Provided Provided
Changeover of impact energy Provided Provided Not indicated
Remaing battery indicator Provided Not provided Not provided
Length (A) 277 mm (10-29/32") 274 mm (10-25/32") 255 mm (10-1/8")
Height (B) 213 mm (8-3/8") 213 mm (8-3/8") 208 mm (8-3/16")Dimensions
Width (C) 76 mm (2-63/64") 76 mm (2-63/64") 73 mm (2-7/8")
Weight 2.4 kg (5.3 lbs) 2.4 kg (5.3 lbs) 2.8 kg (6.1 lbs.)
Type Li-ion Li-ion Li-ion
Attachment Slide type Plug-in type Slide type
Nominal
capacity
3.0 Ah 3.0 Ah 3.0 Ah
Nominal
voltage
18 V 18 V 18 V
Protection
circuit
Provided Provided Not indicated
Battery
Charging
time *1
45 min. 45 min.
22 min.
*1: Charging time may vary depending on the type of charger to be used.
COMPARISONS WITH SIMILAR PRODUCTS
A
B
C
