Hitachi CP-X328 User Manual

18
VIDEO
ASPECT
HOME
END
MUTE
PAG E D OW N
KEYSTONEFREEZE
OFF
ON
MENUPOSITION
ENTER
ESC RESET
PAGE UP VOLUME
MAGNIFY
AUTO BLANK
RGB SEARCH
STANDBY/ON
1
Press the POSITION button
As illustrated on the right, a dialog will appear on the screen
to aid you in adjusting the position.
2
Use the , , , buttons to adjust
the position
When you want to initialize the position, press the RESET
button during adjustment.
Press the POSITION button again to close the dialog and
complete this operation. (Even if you don't do anything, the
dialog will automatically disappear after a few seconds.)
This function is only available for RGB IN 1/2 input.
ADJUSTING THE POSITION
POSITION
POSITION
CP-S317/327W/最終03.5.272:22PMページ18

Hitachi CP-X328 Specifications

General

Resolution	XGA (1024 x 768)
Contrast Ratio	2000:1
Throw Ratio	1.5 - 1.8:1
Projection System	3LCD
Screen Size	30 - 300 inches
Zoom Ratio	1.2x
Weight	3.6 kg
Projection Lens	Manual zoom/focus lens
Video Compatibility	NTSC, PAL, SECAM
Lamp Type	UHB
Input Terminals	VGA (x2), S-Video, Composite Video, Audio (Mini Jack)
Output Terminals	VGA, Audio (Mini Jack)
Power Consumption	310W (Normal mode), 250W (Eco mode)
Keystone Correction	±30° (Vertical)
