MULTIFUNCTIONAL SETTINGS (continued)
INPUT Menu
With the INPUT menu, the four items shown in the Table below can be
performed. With inputting of RGB IN 1 and RGB IN 2 signals, the
horizontal and vertical frequencies of the signals will be displayed on the
initial screen of the INPUT menu.
Perform each operation in accordance with the instructions in the Table.
4
Item Description
AUTO
Auto Adjust (for RGB): Automatically adjusts H POSITION, V POSITION, H
PHASE, and H SIZE. Use this function with the maximum window size.
Auto Adjust (for VIDEO/S-VIDEO): Automatically selects the proper VIDEO
mode for the current input signal. This function is active only when the AUTO
mode is selected for the item VIDEO. Refer to the description for the item
VIDEO below.
• This function may not be available with a PAL60 signal and certain other
signals.
• The AUTO mode operation requires approximately 10 seconds.
• For COMPONENT VIDEO, the signal type is identified automatically even if
this function is inactive. For a HDTV signal, refer to the item HDTV below.
VIDEO
Select Mode of Signal Type (for VIDEO/S-VIDEO):
AUTO ⇔ NTSC ⇔ PAL ⇔ SECAM ⇔
NTSC4.43 ⇔ M-PAL ⇔ N-PAL
Selecting AUTO mode activates and performs the AUTO function for VIDEO/S-
VIDEO. It automatically selects the proper mode from among those above.
Use this function if the image becomes unstable with VIDEO/S-VIDEO. (e.g.
The image becomes irregular, or lacks color.)
• AUTO mode may not function correctly with a PAL60 signal and certain other
signals.
• The AUTO mode operation requires approximately 10 seconds.
• For COMPONENT VIDEO, the signal type is identified automatically even if
this function is inactive. For a HDTV signal, refer to the item HDTV below.
HDTV
Select HDTV Signal Mode:
1080i ⇔ 1035i
• If the selected HDTV mode is incompatible with the input signal, the picture
may be distorted.
SYNC ON G
On/Off SYNC ON G Mode:
TURN ON ⇔ TURN OFF
Selecting TURN ON turns on the SYNC ON G mode. The SYNC ON G mode
allows reception of SYNC on G.
• In the SYNC ON G mode, the picture may be distorted with certain input
signals. In such a case, remove the signal connector so that no signal is
received and turn SYNC ON G off, and then reconnect the signal.
Example : INPUT Menu
(AUTO)
INPUT Menu
To Next Page
