-4-
(c) Curved blade
Blade No. Uses Thickness (mm)
No. 341
For cutting steel and stainless pipes less than 60 mm in outer diameter
2.5 to 6
*The curved blade is not available in some areas.
(d) Section of blades for other materials
Material to be cut Material quality Thickness (mm) Blade No.
2.5 to 9
No. 1, 2, 101, 102, 103, 104, 105, 106,
131, 132
Iron plate Mild steel plate
Below 3.5
No. 3, 107, 108
5 to 20
No. 1, 2, 101, 102, 103, 104, 105, 106,
131, 132
Nonferrous
metals
Aluminum
Copper
Brass
Below 5
No. 3, 107, 108
10 to 50
No. 1, 2, 4, 101, 102, 103, 104, 106, 131,
132
Phenol resin
Melamine resin
5 to 30
No. 3, 5, 8, 105, 106, 107, 108
10 to 60
No. 1, 2, 4, 101, 102, 103, 104, 106, 131,
132
Synthetic resins
Vinyl chloride resin
Acrylic resin
5 to 30
No. 3, 5, 8, 105, 106, 107, 108
