English
11
(2) When cutting metallic materials, use proper
machine oil (turbine oil, etc.). When not using
liquid machine oil, apply grease over the
workpiece.
CAUTION:
The service life of the saw blade will be
drastically shortened if you don’t use
machine oil.
2. Cutting lumber
When cutting lumber, make sure that the
workpiece is fastened firmly before beginning. (Fig.
21)
CAUTION:
Never apply any unreasonable force to the
saw blade when cutting. Also remember to
press the base against the lumber firmly.
3. Sawing curved lines
We recommend that you use the BIMETAL blade
mentioned in Page 14 for the saw blade since it is
tough and hardly breaks.
CAUTION:
Delay the feed speed when cutting the
material into small circular arcs. An
unreasonably fast feed may break the blade.
4. Plunge cutting
With this tool, you can perform pocket cutting on
plywood panels and thin board materials. You can
carry out pocket cutting quite easily with the saw
blade installed in reverse as illustrated in Fig. 23,
Fig. 25, and Fig. 27. Use the saw blade that is as
short and thick as possible. We recommend for
this purpose that you use BI-METAL Blade No. 132
mentioned in Page 14. Be sure to use caution
during the cutting operation and observe the
following procedures.
Fig. 20
Fig. 21
(1) Press the lower part (or the upper part) of the
base against the material. Pull the switch
trigger while keeping the tip of the saw blade
apart from the material. (Fig. 22, Fig. 23)
(2) Raise the handle slowly and cut in with the
saw blade little by little. (Fig. 24, Fig. 25)
Fig. 23
Fig. 22
Fig. 24
Fig. 25
01Eng_CR13V2_US 10/22/08, 18:0811
