Hitachi CS 51EAP User Manual

PART
S
CS 51EAP
DESCRIPTION REMARKS
1 669-8919 START LABEL (C51) (EX) 1
2 669-8568 CLEANER COVER (C51) 1
3 669-8569 SHUTTER PLATE 1
4 669-6903 COVER SET BOLT 7
5 669-8708 CYLINDER COVER (C51) 1
* 6 669-8595 CLEANER KNOB (VERMILION) 1
* 6 669-8596 CLEANER KNOB (GREEN) 1 FOR USA, CAN
7 669-8570 KNOB PACKING 1
8 669-8563 CLEANER ELEMENT (B) 1
9 669-8562 CLEANER ELEMENT (A) 1
10 669-8449 NUT M6 3
11 949-432 BOLT WASHER M6 (10 PCS.) 1
12 669-8429 SPRING HOLDER 1
13 881-722
HEX. SOCKET HD. BOLT (W/FLANGE) M6 X 20 1
14 669-8428 ANTIVIBRATION SPRING 1
15 668-5413 DAMPER SET BOLT 3
16 669-6835 SEAL LOCK SCREW M4 X 10 18
17 669-8539 SCAVENGING COVER (B) 1
18 669-8540 COVER PACKING (C51) 2
19 669-8903 EXHAUST PIPE (C51) 1
20 669-8575 MUFFLER GAUZE (C51) 1
21 305-558
TAPPING SCREW (W/FLANGE) D5 X 25 (BLACK) 2
22 669-8578 FRONT HANDLE 1
23 302-089
TAPPING SCREW (W/FLANGE) D5 X 20 (BLACK) 2
24 949-812 HEX. SOCKET HD. BOLT M4 X 10 (10 PCS.) 5
25 949-429 BOLT WASHER M4 (10 PCS.) 5
26 669-8904 MUFFLER PROTECTOR 1
27 669-8905 MUFFLER PROTECTOR GAUZE 1
28 949-219 MACHINE SCREW M4 X 16 (10 PCS.) 3
29 669-8900 OIL PIPE (CS40) 1
30 669-8554 OIL PUMP 1
31 668-5311 CLIP 5
32 668-5412 SEAL LOCK HEX. SOCKET HD. BOLT M5 4
33 669-8901 SEAL LOCK SCREW M5 X 12 3
34 668-5400 SPIKE 1
35 669-8902
SEAL LOCK HEX. SOCKET HD. BOLT M5 X 45 2
36 669-8706 MUFFLER CAP 2
37 669-8899
SEAL LOCK HEX. SOCKET HD. BOLT M6 X 20 6
38 669-6836
HEX. SOCKET HD. BOLT M5 X 12 (PRECOTE) 5
39 669-8573 MUFFLER (C51) 1
40 669-8576 MUFFLER PACKING (C51) 1
41 668-5308 FUEL GROMMET (A) 1
42 669-8787 GROMMET 1
43 668-5267 FUEL PIPE 2.5 X 4 X 90 1
44 668-5139 PRIMING PUMP COMP. 1
45 669-8541 DECOMP. 1
* 46 668-5782 SPARK PLUG BPMR7A 1
* 46 668-5780 SPARK PLUG BPM-7A 1
47 669-8549 INTAKE PACKING (C51) 1
48 669-8906 INTAKE (CS51) 1
2 - 12 - 3 -
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
ITEM
NO.
NO.
USED
CODE NO.
