Hitachi ED-A110A1DN Service Manual

5
CP-A100 / ED-A100 / ED-A110 (A1DN)
Remote control
(1) STANDBY/ON button
(2) VIDEO button
(3) COMPUTER button
(4) SEARCH button
(5) ASPECT button
(6) AUTO button
(7) BLANK button
(8) MAGNIFY ON button
(9) MAGNIFY OFF button
(10) HOME button
(11) END button
(12) PAGE UP button
(13) PAGE DOWN button
(14) VOLUME button
(15) MUTE button
(16) FREEZE button
(17) MY BUTTON 1 button
(18) MY BUTTON 2 button
(19) KEYSTONE button
(20) FOCUS – button
(21) FOCUS + button
(22) D-ZOOM – button
(23) D-ZOOM + button
(24) POSITION button
(25) MENU button
(26) Cursor Ÿ/ź/Ż/Ź buttons
(27) ENTER button
(28) ESC button
(29) RESET button
(30) Battery cover
Back of
the remote control
(3)
(2)
(5)
(10)
(8)
(9)
(11)
(16)
(17)
(20)
(21)
(24)
(26)
(28)
(4)
(1)
(6)
(7)
(12)
(14)
(15)
(13)
(19)
(18)
(23)
(22)
(25)
(27)
(29)
(30)
VIDEO COMPUTER SEARCH
ASPECT AUTO BLANK
ON
OFF
MAGNIFY
HOME PAGE UP VOLUME
END
PAGE DOWN MUTE
FREEZE MY BUTTON KEYSTONE
1 2
FOCUS D-ZOOM
- + - +
POSITION MENU
ENTER
ESC RESET

Hitachi ED-A110A1DN Specifications

General

Brand	Hitachi
Model	ED-A110A1DN
Category	Projector
Language	English
