68
CP-A100 / ED-A100 / ED-A1
10 (A1DN)
Never attach the fan to the wrong direction.
Never attach the fan to the wrong direction.
Turn the cable output to the left.
Turn the cable output
to the upper.
8. Attaching the circuit power unit fan
9. Attaching the ballast unit fan
67
69
