Hitachi G 18DSL Handling Instructions

9
○ Since the built-in micro computer takes about 3
seconds to confi rm that the battery being charged with
charger is taken out, wait for a minimum of 3 seconds
before reinserting it to continue charging. If the battery
is reinserted within 3 seconds, the battery may not be
properly charged.
○ If the pilot lamp or charge indicator lamp does not blink
in red (every second) even though the charger cord is
connected to the power, it indicates that the protection
circuit of the charger may be activated.
Remove the cord from the power and then connect it
again after 30 seconds or so.
If this does not cause the pilot lamp or charge indicator
lamp to blink in red (every second), please take the
charger to the Hitachi Authorized Service Center.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the battery 111
Charging 2 11
Fitting and adjusting the wheel
guard
311
Fitting and adjusting the wheel
guard (for cutting)
411
Fixing the side handle 5 11
Assembling depressed center
wheel
612
Assembling cutting wheel 7 12
Switch operation 8 12
Grinding angle and grinding method 912
Remaining battery indicator 10 12
Check and replacing the carbon
brush
11 13
Charging a USB device from an
electrical outlet
12-a 13
Charging a USB device and
battery from an electrical outlet
12-b 13
How to recharge USB device 13 14
When charging of USB device is
completed
14 14
Selecting accessories ― 15
MAINTENANCE AND INSPECTION
1. Inspecting the depressed center wheel
Ensure that the depressed center wheel is free of cracks
and surface defects.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Inspecting the carbon brushes (Fig. 11)
The motor employs carbon brushes which are
consumable parts. Since and excessively worn carbon
brush can result in motor trouble, replace the carbon
brush with new ones when it becomes worn to or near
the “wear limit” ⓐ. In addition, always keep carbon
brushes clean and ensure that they slide freely within the
brush holders.
NOTE
When replacing the carbon brush with a new one, be
sure to use the Hitachi Carbon Brush Code No. 999054.
5. Replacing carbon brushes (Fig. 11)
Take out the carbon brush by fi rst removing the brush
cap and then hooking the protrusion of the carbon brush
with a fl at head screw driver, etc.
When installing the carbon brush, choose the direction
so that the nail ⓑ of the carbon brush agrees with the
contact portion ⓒ outside the brush tube. Then push it in
with a fi nger. Lastly, install the brush cap.
CAUTION
Be absolutely sure to insert the nail of the carbon brush
into the contact portion outside the brush tube. (You can
insert whichever one of the two nails provided).
Caution must be exercised since any error in this
operation can result in the deformed nail of the carbon
brush and may cause motor trouble at an early stage.
6. Cleaning on the outside
When the cordless disc grinder is stained, wipe with a
soft dry cloth or a cloth moistened with soapy water. Do
not use chloric solvents, gasoline or paint thinner, for
they melt plastics.
7. Storage
Store the cordless disc grinder in a place in which the
temperature is less than 40°C, and out of reach of
children.
NOTE
Storing lithium-ion batteries.
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
signifi cantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, signifi cantly reduced battery usage time may
be recovered by repeatedly charging and using the
batteries two to fi ve times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries dead
and purchase new batteries.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
Important notice on the batteries for the Hitachi
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used with
batteries other than these designated by us, or when
the battery is disassembled and modifi ed (such as
disassembly and replacement of cells or other internal
parts).
NOTE
Due to HITACHI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
