Hitachi H 41SD - General Assembly

-8-
MODEL
Variable
Fixed
10 20 30 40 50 60 min
H 41SD
General Assembly
O-ring
Second
Hammer
Damper
Washer
Damper
O-ring (A)
Handle
Cylinder
Striker
O-ring x 2
Piston
Connecting
Rod
Needle
Bearing
Gear Cover
Ass’y
Needle Bearing
Armature
Ball Bearing
(6201DD)
Ball Bearing
(608VV)
Crank Shaft
Ball Bearing
(6203DD)
Oil Seal
First Gear
Housing Ass’y
Stator Ass’y
Crank Case
Work Flow
Handle Cover
Switch (B)
Cord
Cord Armor
Tail Cover
Crank Cover
O-ring
Retainer
Damper
Hammer
Holder
Cylinder Case
Ass’y
STANDARD REPAIR TIME (UNIT) SCHEDULES
