General| Phase | 1 or 3 |
|---|---|
| Control Voltage | 24V |
| Chain Falls | 1 or 2 |
| Load Chain Grade | Grade 80 |
| Ambient Temperature Range | -20°C to 40°C |
| Duty Class | H4 |
| Capacity | 0.5 to 5 tons |
Explains danger, warning, and caution ranks for safety precautions.
Defines symbols for prohibited actions and required instructions.
Emphasizes routine checks before use and stopping immediately if abnormalities are found.
Covers checks for operation without load and braking effectiveness under rated load.
Recommends monthly and annual inspections by experts and using genuine parts.
Provides step-by-step instructions for disassembling hoist components.
Explains how to check the wear and operation status of the electromagnetic brake.
Details the procedure for adjusting the electromagnetic brake gap.
Guides on inspecting hooks for cracks, wear, opening size, and thickness.
Outlines methods for checking chain lubricant, elongation, and wear.
