Hitachi P 20SF Service Manual

PART
S
P 20SF
DESCRIPTION REMARKS
* 1 334-480 CUTTER BLOCK ASS'Y (W/B.B) 1 INCLUD. 17, 19 EXCEPT FOR IND
* 2 879-418 PLANER BLADES (1 PAIR) 2 FOR DOUBLE EDGE BLADE TYPE
* 3 334-478 SET PLATE (B) (1 PAIR) 2 FOR DOUBLE EDGE BLADE TYPE
* 4 314-754 SET PLATE (A) 2 EXCEPT FOR IND
* 5 949-423 WASHER M4 (10 PCS.) 4 EXCEPT FOR IND
* 6 949-213 MACHINE SCREW M4 X 5 (10 PCS.) 4 EXCEPT FOR IND
* 7 316-398 BLADE HOLDER (1 PAIR) 2 EXCEPT FOR IND
8 334-706 WASHER 65MN T0.5 6
9 334-707 BOLT M6 6
* 10 314-746 PLANER BLADES 82 MM (1 PAIR) 2 EXCEPT FOR DOUBLE EDGE BLADE TYPE
* 11 949-216 MACHINE SCREW M4 X 10 (10 PCS.) 4 EXCEPT FOR DOUBLE EDGE BLADE TYPE FOR IND
* 12 958-731Z HOLDER SPRING (B) 4 EXCEPT FOR DOUBLE EDGE BLADE TYPE FOR IND
* 13 958-732Z GUARD PLATE (A) 4 EXCEPT FOR DOUBLE EDGE BLADE TYPE FOR IND
* 14 958-734Z BLADE HOLDER (1 PAIR) 2 EXCEPT FOR DOUBLE EDGE BLADE TYPE FOR IND
* 15 958-728 PLANER BLADES 82 MM (1 PAIR) 2 EXCEPT FOR DOUBLE EDGE BLADE TYPE FOR IND
* 16 958-733Z BACK METAL 2 EXCEPT FOR DOUBLE EDGE BLADE TYPE FOR IND
17 608-VVM BALL BEARING 608VVC2PS2L 1
* 18 334-481 CUTTER BLOCK ASS'Y (W/B.B) 1 INCLUD. 11-13, 17, 19 EXCEPT FOR
DOUBLE EDGE BLADE TYPE FOR IND
19 620-0VV BALL BEARING 6200VVCMPS2L 1
20 958-945 SCREW PLATE 1
21 954-004 TAPPING SCREW D4 X 16 1
22 958-709 SPRING 1
23 958-708 RUBBER PACKING 1
24 334-739 FRONT BASE 1
25 334-494 KNOB (A) 1
26 334-497 LOCK NUT M10 1
* 27 334-488 KNOB (B) 1
* 27 334-489 KNOB (B) 1 FOR USA, CAN
28 301-659 WASHER (B) 1
29 334-492 BEARING COVER 1
30 309-470
TAPPING SCREW (W/FLANGE) D4 X 12 (BLACK) 2
31 334-501 TIP COVER 1
32 301-653
TAPPING SCREW (W/FLANGE) D4 X 20 (BLACK) 8
33 938-477 HEX. SOCKET SET SCREW M5 X 8 2
34 NAME PLATE 1
35 957-571 BRUSH HOLDER 2
36 999-021 CARBON BRUSH (1 PAIR) 2
37 931-266 BRUSH CAP 2
* 38 334-736 CORD HOLDER 1
* 38 334-498 CORD HOLDER 1 FOR TPE, UAE, USA, CAN, MEX, BRA,
PAN (120 V), NOR, SWE, DEN, FIN
39 334-487 BELT COVER 1
40 958-718 BELT 1
41 334-491 PULLEY (B) 1
42 334-486 END BRACKET 1
43 620-0VV BALL BEARING 6200VVCMPS2L 1
44 334-713 WASHER (A) 1
* 45 360-936U ARMATURE ASS'Y 110 V-120 V 1 INCLUD. 43, 57
* 45 360-936H ARMATURE 110 V 1 FOR GBR (110 V), UAE, TPE
- 2 - 10 - 12
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
ITEM
NO.
NO.
USED
CODE NO.

Hitachi P 20SF Specifications

General

Input power	620 W
Power source	AC
Idle speed	17000 RPM
Planning width (max)	82 mm
Chip thickness (max)	2.6 mm
Soft grip	Yes
Product color	Green

Weight and Dimensions

Width	296 mm
Weight	2500 g
